Watchdog Submenu - Congatec conga-IA4 User Manual

Main Advanced
UEFI Network Stack
CSM & Option ROM Control
Info Report Configuration
NVMe Configuration
SDIO Configuration
USB
Diagnostic Settings
Platform Trust Technology
Security Configuration
IntelMRT Configuration
PC Speaker
8.4.1

Watchdog Submenu

Feature Options
POST Watchdog Disabled
30sec
1min
2min
5min
10min
30min
Stop Watchdog for No
Yes
User Interaction
Runtime Watchdog Disabled
One-time Trigger
Single Event
Repeated Event
Delay Disabled
10sec
30sec
1min
2min
5min
10min
30min
Copyright © 2016 congatec AG
Chipset
Description
Set the timeout value for the POST watchdog. The watchdog is only active during
the POST of the system and provides a facility to prevent errors during boot up by
performing a reset.
Select whether the POST watchdog should be stopped during the popup of the boot
selection menu or while waiting for the setup password.
Select the operating mode of the runtime watchdog:
'One-time Trigger' - Disables watchdog after first trigger.
'Single Event' - Executes every stage only once before the watchdog is disabled.
'Repeated Event' - Executes last stage repeatedly until reset.
Note: This watchdog will be initialized just before the operating system starts booting.
The runtime watchdog is delayed for the selected time.
Note: Use this feature to ensure that the operating system has enough time to load.
Boot Security
IA40m12.indd
Save & Exit
60/97
