Chapter 3-Cascading Conferences

Setting up MIH Cascading Conferences

3-40
• The following table lists the bit rate allocated to the Content channel
from the video channel in each of the three Content modes:
Table 3-3 Bit Rate Allocation to Content Channel
Conf Kbps 64/
/ Mode 96
Graphics 0
Hi-res 0
Graphics
Live Video 0
The cascading topology, the master/slave relationship and the dialing
direction determines the set-up procedure:
• RMX to RMX
• MGC to RMX
• MGC to MGC
For more details about the MGC to MGC connection, see the MGC
Manager User's Guide, Volume II, Chapter 1, "Ad Hoc Auto Cascading and
Cascading Links".
RMX to RMX Cascading
Level 1 (Master)
Figure 3-5 Dialing Direction
To establish the links between two RMXs requires the following
procedures be performed:
• Establish the Master-Slave relationships between the cascaded
conferences by defining the dialing direction.
128 256 384 512
64 64 128 128
64 128 192 256
64 128 256 384
768 1024 1472
256 256 256
384 384 512
512 768 768
Level 2 (Slave to Level 1)
1920
256
512
768
