Close Chime
Default = 0 (Off)
If on, a chime will sound whenever a zone is restored. See Table
B1 on page 79 for the zone types that chime.
To Turn Close Chime Setting On/Off:
Once the item number has been entered, enter 1 to turn the setting
on or 0 to turn it off. Press # to apply the new setting.
Zone Test Time Out
Default = 30 Minutes
Enter the length of time (in minutes) after which a zone test auto-
matically times out (ends).
Setting the Zone Test Time Out:
Once the item number has been entered, enter the number of min-
utes (5–120) before a zone test ends and press #.
Unlock Button Action (Default = 4)
Lock Button Action (Default = 9)
Lights Button Action (Default = 15)
Star Button Action (Default = 12)
Lights/Star Button Combination Action
(Default = 3)
Direct Arm Level—3 Action (Default = 6)
Direct Arm Level—2 Action (Default = 5)
Lock/Star Button Combination Action
(Default = 16)
Disarm/Lights Button Combination Action
(Default = 16)
These settings allow you to specify how the system behaves when
specific keychain touchpad button or button combinations are
pressed.
Special Action Assignments:
q
0- not used
q
1- not used
q
2- not used
q
3- auxiliary panic (only used for item no. xx061)
q
4- arm to level 1
q
5- arm to level 2
q
6- arm to level 3
q
7- arm to special level 4
q
8- arm to special level 5
q
9- arm to closed level
q
10- arm to closed level with no delay
q
11- arm to closed level with Latchkey
q
12- increment arming level from 0 to 1, 1 to 2, or 2 to 3 only
q
13- turn all* lights on
q
14- turn all* lights off
q
15- toggle all* lights
q
16- do nothing
* all lights having the first (of two) house codes in the partition.
Specifying Keychain Touchpad Button Action:
1. Once the desired item number has been entered, enter the spe-
cial action assignment number (3–16) from the above list.
2. Press # to apply the new setting.
Commercial Burglary and Home Navigator System
xx111
Auxiliary Medical Panic Keys
Default = 1 (On)
Choose whether or not to enable the Auxiliary panic buttons on
touchpads. If enabled, when a user presses and holds the Auxil-
iary panic buttons or presses them twice, an auxiliary or medical
alarm is generated. See Auxiliary/Medical Assignment setting
(xx084).
To Turn This Setting On/Off:
Once the item number has been entered, enter 1 to turn the setting
on (enabled) or 0 to turn it off. Press # to apply the new setting.
xx011
Enable Police Panic Keys
Default = 1 (On)
Choose whether or not to enable the Police panic buttons on
touchpads. If enabled, when a user presses and holds the police
panic buttons or presses them twice, a police alarm is generated.
To Turn This Setting On/Off:
Once the item number has been entered, enter 1 to turn the setting
on (enabled) or 0 to turn it off. Press # to apply the new setting.
xx057
xx058
xx059
xx060
xx061
Enable Fire Panic Keys
Default = 1 (On)
xx063
Choose whether or not to enable the Fire panic buttons on touch-
xx064
pads. If enabled, when a user presses and holds the fire panic but-
xx065
tons or presses them twice, a fire alarm is generated.
xx066
To Turn This Setting On/Off:
Once the item number has been entered, enter 1 to turn the setting
on (enabled) or 0 to turn it off. Press # to apply the new setting.
Auxiliary/Medical Assignment
Default = 1 (On–Auxiliary Alarm)
Choose whether the Auxiliary/Medical panic buttons are used to
produce an auxiliary (on) or medical (off) alarm.
Note
In order for an auxiliary or medical alarm to be produced
by the pressing of the panic buttons, they must be
enabled. See the Auxiliary Medical Panic Enable setting
xx086.
Selecting the Alarm Type:
Once the item number has been entered, enter 1 to turn the setting
on (auxiliary) or 0 to turn it off (medical). Press # to apply the
new setting.
Codes
The settings below cover only installer programming codes.
For information on user access code programming, please
refer to the User's Guide.
Programming the Panel
xx086
xx085
xx087
xx084
23
