Note
Lights and devices must be added (learned) before they
can be accessed using the Lights or Devices menus.
To test lights and devices:
1. Press
to test lights or
4
/
shows
ENTER A LIGHT
DEVICE NUMBER THEN PRESS
2. Enter the desired light or device number to test and press
.
#
3. Press
to select Turn [selected light or device] on now.
1
4. Verify that the light or device is on.
5. Press
to select Turn [selected light or device] off now.
2
6. Verify that the light or device is off.
7. Press the Lights On or Lights Off buttons twice to turn
all lights on the first house code on or off at the same
time.
Note
Appliance and universal X-10 modules, if any, are all
turned off by pressing Lights Off but are not turned on by
pressing Lights On.
8. Repeat steps 2–6 for remaining light or device numbers
that are used in all partitions/areas.
9. Press
to return to the main menu.
*
Testing Phone Communication
Perform a phone test to check phone communication between
the panel and the central station.
To perform a phone test:
1. Contact the central station to inform them that you are
testing the system.
2. Make sure all premises telephones are on-hook (hung
up).
3. Press
. The display shows
0
4. Press
+
1
primary access code
.
PHONE TEST
Note
Refer to Table A12 on page 45 for default access codes.
5. Wait for the system to dial and test all programmed tele-
phone numbers.
6. The panel indicates
PHONE TEST OK
ber successfully tested.
7. Press * quit the phone test.
Note
n
If
NUMBER
TEST FAILURE
test and refer to the "Troubleshooting" section.
Commercial Burglary and Home Navigator System
to test devices. The display
5
#.
.
PHONE MENU
+
. The display shows
#
for each phone num-
*
is indicated, press
to quit the
Testing Central Station Communication
After performing zone and phone tests, check that the sys-
tem is reporting alarms successfully to the central station
and pager(s).
&$87,21
Be sure to contact the central station before activating
outputs/zones that trigger an alarm condition.
To test communication with the central station:
1. Call the central station and tell the operator that you will
be testing the system.
2. Arm the system.
3. Test each touchpad, wireless panic button, and trip all of
the sensors. Verify that the appropriate system indica-
tions and alarms are working correctly.
4. Make sure that you test all programmed central station
phone numbers, and all partitions/areas.
5. When you finish testing the system, call the central sta-
tion to verify that all of the correct alarms were
received. Check pager displays to verify that reports
were received.
Adjusting Touchpad Display Contrast
Touchpad displays can be adjusted for easier viewing to
help compensate for lighting conditions in the touchpad
location. The contrast adjustment lightens or darkens the
text.
Note
When performing the procedure below you may get a
Bus Communication Failure. This is because the panel
takes the touchpad off-line when adjusting the contrast.
To adjust display contrast:
1. Enter configuration mode by pressing the
tons together for at least two seconds. The display
shows
nnn .
DA
2. Press and release the
and
1
until the desired contrast level is displayed.
3. Press
and the display briefly shows
*
the time and date.
Note
For information on adjusting display backlighting and
brightness, please see the specific Advent panel User
Guide.
Vacuum fluorescent displays do not have a contrast
adjustment.
Testing the System
and
but-
D
6
buttons together repeatedly
2
, then shows
DONE
47
