Determining Maximum Panel Wire Length

Example:
Using 22 gauge wire to connect the following devices on
one wire run (length of cable):
Device Current Draw (see note)
1- Hardwire 2-Line Alpha Touchpad = 120 mA
1- RF Transceiver Module = 50 mA
1-8Z Hardwire Input Module = 35 mA
Total Device Current Draw = 205 mA
Find the total device current draw in the table and match the
wire type used. In this example, the maximum recom-
mended wire length is about 154 feet. For longer lengths,
use a larger gauge wire.
Note
For self- or remotely-powered devices, the maximum rec-
ommended wire length is 4,000 feet using 18 gauge or
larger wire.
Table A2: Max. Wire Length Recommendations*
Total
Device
22 Gauge
Current
(AWG)
Draw
(mA)
100 616
200 308
300 206
400 154
500 124
600 104
700 88
800 78
900 70
1000 61
1100 56
1200 54
1300 48
1400 44
1500 42
1600 40
1700 36
1800 34
1900 32
2000 30
2100 29
2200 28
2300 27
2400 26
2500 25
Commercial Burglary and Home Navigator System
18 16 14
Gauge Gauge Gauge
(AWG) (AWG) (AWG)
1,562 2,486 3,936
782 1,244 1,968
522 830 1314
392 622 982
314 500 792
262 416 653
224 356 564
196 312 492
174 278 438
156 250 394
142 226 358
130 208 330
120 192 304
112 178 282
104 166 264
98 156 246
92 146 232
88 138 216
82 132 208
78 126 198
74 120 188
72 114 180
68 108 172
66 104 164
64 100 158
Appendix A: System Configuration Worksheets
Table A2: Max. Wire Length Recommendations*
Total
Device
22 Gauge
Current
(AWG)
Draw
(mA)
2600 24
2700 23
2800 22
2900 21
3000 20
*Two volt maximum loop voltage drop.

Other System Devices

Table A3: Wireless Sensors
Part No.
60-348 Handheld Wireless Touchpad
60-362 Learn Mode Door/Window Sensor
60-409 Learn Mode Recessed Door/Window Sen-
sor
60-452 Learn Mode Pendant Panic Sensor
60-453 Wall-Mount Wireless Touchpad
60-457 Dual Button Panic Sensor
60-458 Single Button Panic Sensor
60-460 Rate-of-Rise Heat Sensor
60-461 Learn Mode Shock Sensor
60-462 Learn Mode Glass Guard Sensor
60-499 Learn Mode Slim Line Door/Window
Sensor
60-504 Learn Mode Freeze Sensor
60-506-319.5 Learn Mode Smoke Sensor
60-838 Learn Mode Smoke Sensor (System Sen-
sor) 2100ARFT
60-848-95 Learn Mode Smoke Sensor (ESL) 560
Series
60-849-95 Learn Mode Smoke Sensor (ESL) 570
Series
60-511 Learn Model DS924i PIR Motion Sensor
60-578 Water-Resistant Panic Sensor
60-582 Learn Mode Sound Sensor (IntelliSense)
60-641 Learn Mode Long Life Door/Window
Sensor
60-688 Learn Mode Micro Door/Window Sensor
60-741 Learn Mode Recessed Micro Door/Win-
dow Sensor
Table A4: X-10 Module Line Carrier Devices
Part No. Description
13-399 X-10 Universal Module
13-402 X-10 Appliance Module
13-403 X-10 Lamp Module
18 16 14
Gauge Gauge Gauge
(AWG) (AWG) (AWG)
60 96 152
58 92 146
56 90 140
54 86 136
52 84 132
Description
Qty.
Qty.
