Enable Daylight Savings Time Adjust
Default = 1 (On)
This setting allows you to select whether or not the panel adjusts
to daylight savings time. If on, the clock makes daylight savings
adjustments at 2:00 AM on the first Sunday in April and the last
Sunday in October. The time will spring ahead from 01:59 to
03:00 or fall back from 01:59 to 01:00.
To Turn Daylight Savings Time Adjust On/Off:
1. Once the item number has been entered, enter 1 for on, or 0
for off.
2. Press # to apply the new setting.
Print System Events
Default = 1 (On)
This setting allows you to select whether or not to print system
events.
Note
This setting only enables the printing of system events.
See Print Partition/Area Events setting (xx091) to enable
partition/area event printing.
To Turn Print System Events On/Off:
1. Once the item number has been entered, enter 1 for on, or 0
for off.
2. Press # to apply the new setting.
Print Line Feed after Carriage Return
Default = 1 (On)
This setting allows you to select whether or not to print a line feed
after a carriage return. This will tell the printer to print a line feed,
creating an extra blank line.
Some printers have an auto line feed setting. If the printer adds its
own extra line feed, disable this setting so that it doesn't print
extra blank lines. Check the printer manual for details.
To Turn Print Line Feed after Carriage Return On/Off:
1. Once the item number has been entered, enter 1 for on, or 0
for off.
2. Press # to apply the new setting.
Printer Supports Epson ESC/P Protocol
Default = 1 (On)
Turn this setting on if the printer attached to the panel supports
ESC/P protocol. Check the printer manual for details.
To Turn Epson ESC/P Protocol On/Off:
1. Once the item number has been entered, enter 1 for on, or 0
for off.
2. Press # to apply the new setting.
Commercial Burglary and Home Navigator System
17070
AC Report Delay
Default = 6 Hours
This setting allows you to select the hours to delay (in addition to
random 0–30 minute delay) before the panel reports AC power
failure to the central station.
To Set AC Report Delay:
1. Once in program mode enter the item number.
2. Enter the desired delay (0–36) and press #.
Low Battery Voltage
Default = 180 (10.6V)
This setting allows you to specify the backup battery voltage at
17099
which low battery trouble is generated (set in 1/17 volt units).
To Set Low Battery Voltage:
1. Once in program mode enter the item number.
2. Enter the desired voltage (172–188 [10.1–11.1V]) and press #.
Battery Restored Voltage
Default = 196 (11.6V)
This setting allows you to set the voltage at which a low battery
trouble restoral is generated (set in 1/17 volt units).
To Set Battery Restoral Voltage:
1. Once in program mode enter the item number.
2. Enter the desired voltage (188–204 [11.1–12.0V]) and press #.
17097
Start Shutdown Battery Voltage
Default = 159 (9.4V)
This setting allows you to set the backup battery voltage at which
a system shutdown (during an AC power failure) is started (set in
1/17 volt units).
To Set Start Shutdown Voltage:
1. Once in program mode enter the item number.
2. Enter the desired voltage (151–167 [8.9–9.8V]) and press #.
Cancel Shutdown Battery Voltage
17124
Default = 176 (10.4V)
This setting allows you to set the backup battery voltage at which
a system shutdown (during an AC power failure) is canceled (set
in 1/17 volt units).
To Set Cancel Shutdown Voltage:
1. Once in program mode enter the item number.
2. Enter the desired voltage (168–184 [9.9–10.8V]) and press #.
Programming the Panel
17041
17037
17038
17039
17040
41
