P A N E L T E R M I N A L S T R I P
2 - W I R E
S M O K E L O O P
+ 1 2 V
S W
+
2 1
+
+
2 . 0 K O H M
E O L R E S I S T O R
4 9 - 4 6 7
( I N S T A L L A T L A S T D E V I C E )
Figure 15. Connecting 2-Wire Smoke Detectors

Connecting Speakers

The panel provides one speaker driver output for intrusion
(steady), fire (temporal 3), and auxiliary (on-off-on-off)
alarm sounds.
Note
The speaker output is used for partition/area 1 only.
The output can drive a single 8-ohm speaker or multiple
speaker circuit of 4- to 8-ohms (as shown in the following
speaker wiring diagrams). Comparable speakers are
described below and on the following page.
&$87,21
To avoid damage to the panel speaker output, do not
make speaker connections with the panel powered up.
15-Watt Speaker (13-060) 30-Watt Speaker (13-061)
Use this speaker for interior siren applications such as status
and voice. When wiring multiple speakers, the total imped-
ance for all speakers must be between 4 and 8 ohms. Con-
nect the speaker(s) to the panel as shown in Figure 16. For
mounting instructions please refer to the Installation
Instructions included with the speaker.
Commercial Burglary and Home Navigator System
–
2 2
L I S T E D 2 - W I R E ,
1 2 V S M O K E / H E A T
–
D E T E C T O R
( U S E I N - A N D - O U T
– [ D A I S Y - C H A I N ]
M U L T I P L E D E V I C E
W I R I N G M E T H O D S
O N L Y . )
2 . 0 K O H M
E O L R E S I S T O R
( R E D ) 4 9 - 4 6 7
( L O C A T E A T
L A S T D E V I C E )
O N E 8 O H M S P E A K E R
1 3 - 0 6 0 ( 1 5 W A T T )
O R 1 3 - 0 6 1 ( 3 0 W A T T )
O R
T W O 8 O H M
S P E A K E R S
I N P A R A L L E L
( 4 O H M S )
2 2 0 M . , 3 5 V
C A P A C I T O R
( N O N - P O L A R I Z E D )
1 7 - 1 0 1
( L O C A T E A T
D E V I C E )
Figure 16. Connecting 15- and 30-Watt Interior
Speakers
Hardwire Interior Speaker and Piezo (60-252)
Use this speaker for interior siren applications. Connect the
speaker to the panel as shown in Figure 17. When wiring
multiple speakers, stay between 4 and 8 ohms.
H A R D W I R E I N T E R I O R
S P E A K E R A N D P I E Z O 6 0 - 2 5 2
2 . 0 K O H M
E O L R E S I S T O R
4 9 - 4 6 7
( L O C A T E A T
L A S T D E V I C E )
4 5 9
+ 1 2 I N T . V O I C E
V D C B E L L S I R E N
Figure 17. Connecting a Hardwire Interior Speaker and
Piezo
Hardwire Interior Speaker (60-528)*
Use this speaker unit for interior siren applications. Connect
1 speaker to the panel as shown in Figure 18. Connect mul-
tiple speakers to the panel as shown in Figure 19.
* Not investigated by UL.
Installing the System
P A N E L T E R M I N A L S T R I P
V O I C E V O I C E
S I R E N S I R E N
1 0
9
P A N E L T E R M I N A L S T R I P
V O I C E V O I C E
S I R E N S I R E N
1 0
9
2 . 0 K O H M
E O L R E S I S T O R
( R E D ) 4 9 - 4 6 7
( L O C A T E A T
L A S T D E V I C E )
*
R E D
B L A C K
2 2 0 M . , 3 5 V
C A P A C I T O R
( N O N - P O L A R I Z E D )
1 7 - 1 0 1
( L O C A T E A T
D E V I C E )
1 0
P A N E L T E R M I N A L S
V O I C E
S I R E N 8 5 4 3 1 4 0 A . D S .
