Programming the Panel
I/O Settings
Use the following item numbers to specify how inputs and
outputs behave.
General Input Response Time 1
General Input Response Time 2
General Input Response Time 3
General Input Response Time 4
General Input Response Time 5
General Input Response Time 6
General Input Response Time 7
Defaults = 32 (0.512 Seconds)
Each of the seven onboard (snapcard) inputs has a response time.
The panel has to "see" a transition for at least that length of time
in order to deem it a trip or restoral. At the panel you enter
response times in 16 millisecond increments (actual time = value
x 16 ms).
To Program a General Input Response Time:
1. Enter the desired item number.
2. Enter a response time (8–255) and press #.
Expansion Input Response Time 1
Expansion Input Response Time 2
Expansion Input Response Time 3
Expansion Input Response Time 4
Expansion Input Response Time 5
Expansion Input Response Time 6
Expansion Input Response Time 7
Expansion Input Response Time 8
Defaults = 32 (0.512 Seconds)
Each of the eight expansion inputs has a response time. The panel
has to "see" a transition for at least that length of time in order to
deem it a trip or restoral. At the panel you enter response times in
16 millisecond increments (actual time = value x 16 ms).
To Program an Expansion Input Response Time:
1. Enter the desired item number.
2. Enter a response time (8–255) and press #.
General Purpose I/O 1 Direction
General Purpose I/O 2 Direction
General Purpose I/O 3 Direction
General Purpose I/O 4 Direction
General Purpose I/O 5 Direction
General Purpose I/O 6 Direction
Defaults = 0 (Input)
Select the direction of each general purpose input/output.
To Program General Purpose Input/Output direction:
1. Enter the desired item number.
2. Enter 1 to set the direction as an output, or 0 to set it as an
input. Press # to apply the direction.
34
Activation Interval One-Shot Time A
(Default = 4 Seconds)
Activation Interval One-Shot Time B
17006
(Default = 30 Seconds)
17007
Activation Interval One-Shot Time C
17008
(Default = 180 Seconds)
17009
Activation Interval One-Shot Time D
17010
(Default = 900 Seconds)
17011
Specify how long (in-seconds) outputs are activated when the
17118
response is set to one-shot.
Note
Only those outputs programmed to be one-shot (A, B, C,
or D) will be affected by this setting.
To Program One-Shot Time:
1. Enter the desired item number.
2. Enter the desired one-shot time duration (1–999) and press #.
Output Delay Time
(Default = 30 Seconds)
17012
Specify how long (in-seconds) output activation is delayed.
17013
Note
17014
Only those outputs that are programmed to be delayed
17015
will be affected by this setting.
17016
17017
To Program the Output Delay Time:
17119
17120
1. Enter the desired item number.
2. Enter the desired delay time (1–999) and press #.
Accessory Modules
The items below allow you to add, delete, list, and modify
SuperBus 2000 devices and settings.
Add (Learn) Bus Devices
Default = NA
Use this item number to force the panel to scan for bus devices
once they have been correctly connected to the panel.
Note
17063
All SuperBus 2000 devices are added to partition/area 1
17064
initially. Use item number 48004 (Bus Device Partition/
17065
Area) to assign devices to different partitions/areas once
17066
added.
17067
17068
To Force the Panel to Scan for Bus Devices:
Once in program mode enter 48001. The display will show
, then it will list the added devices as shown.
DEVICES ADDED
DEVICE
Where n is the 2-digit device number (01–62), xxxxxxxx is the 8-
digit ID number (address), and
(1–8).
nn
xxxxxxxx
/
ID
PARTITION
AREA
is the partition/area number
Z
Commercial Burglary and Home Navigator System
17113
17114
17115
17116
17112
48001
z
