Scheduled Arming Period
Default = 10 Minutes
This is the amount of time between the start of arming notification
and when the partition/area is armed by a schedule (auto arming).
This notifies users that a scheduled arm is about to occur and
allows time for users to vacate the premises.
To Set the Scheduled Arming Period:
Once the item number has been entered, enter the number of min-
utes (05–30) that will pass between notification and arming. Press
# to apply the new setting.
Scheduled Arming Extension
Default = 30 Minutes
This is the amount of time by which a scheduled arming period
will be suspended during the arming notification period. For
example, let's say the extension is entered when there is four min-
utes left in the delay. Once the extension has expired the system
will start counting down the remaining four minutes.
To Set the Scheduled Arming Extension:
Once the item number has been entered, enter the number of min-
utes (15–120) users will be able to extend the notification period
and press #.
Auto Forced Arming
Default = 1 (On)
If on, any protesting zone(s) will be bypassed upon arming. If off,
then the partition/area will not arm if any zone(s) are protesting.
To Turn Auto Forced Arming On/Off:
Once the item number has been entered, enter 1 to turn the setting
on or 0 to turn it off. Press # to apply the new setting.
Quick Arm
Default = 1 (On)
If on, anyone can arm the panel and increase arming levels with-
out an access code. A valid access code is still required to
decrease arming levels or disarm the system. Quick arm works as
follows:
o Level 3 to 5 = no code
o Level 3 to 4 = code
o Level 4 to 3 = no code
o Level 5 to 3 = code
To Turn Quick Arming On/Off:
Once the item number has been entered, enter 1 to turn the setting
on or 0 to turn it off. Press # to apply the new setting.
Commercial Burglary and Home Navigator System
xx007
xx008
xx092
xx093
o Level 1 to 2 = no code
o Level 1 to 3 = no code
o Level 1 to 4 = no code
o Level 1 to 5 = no code
Exterior Siren Arming Verification
Default = 0 (Off)
If on, exterior sirens will produce arming verification sounds noti-
fying users that the system was armed.
Note
In order for this setting to work, Local Closing Report
Verification setting (xx098) must be set to "on."
To Turn Exterior Siren Arming Verification On/Off:
Once the item number has been entered, enter 1 to turn the setting
on or 0 to turn it off. Press # to apply the new setting.
Bypass Limit
Default = 250/132 (all zones)
Select the number of zones that may be bypassed at once. See
Table B1 on page 80 for information on which zone types may be
bypassed.
To Program Bypass Limit
Once the item number has been entered, enter the number of
zones that may be bypassed at once (0–250). Press # to apply the
new setting.
Automatic Unbypass Enable
Default = 0 (Off)
If on, an indirectly bypassed zone will automatically be unby-
passed once the door, window, etc., has been closed for 30 sec-
onds. This setting only applies to delayed zones.
To Turn Automatic Unbypass Enable On/Off:
Once the item number has been entered, enter 1 to turn the setting
on or 0 to turn it off. Press # to apply the new setting.
Swinger Bypass Enable
Default = 1 (On)
If on, a zone that exceeds the set swing count (xx021) during a
single arming period will automatically be bypassed. Changing
the arming level restores all automatically bypassed zones and
resets the swing count.
To Turn Swinger Bypass Enable On/Off:
Once the item number has been entered, enter 1 to turn the setting
on or 0 to turn it off. Press # to apply the new setting.
Swing Count (Auto Bypass Trips
Default = 3
Select the maximum number of report attempts that one zone can
generate during a single arming period before the panel automati-
cally bypasses that zone.
All automatically bypassed zones, and the swing count, will reset
if the system clock reaches midnight or an arming level change
occurs.
To Set the Swing Count:
Once the item number has been entered, enter the desired swing
count (1–8) and press # to apply the new setting.
Programming the Panel
xx097
xx017
xx096
xx095
xx021
21
