Interlogix Advent Installation Instructions Manual page 5

(60-783) for use with a listed printer.
q SuperBus 2000 Dual Phone Line Module (60-768) for
expansion to primary and secondary phone line report-
ing.
System Setup and Programming
The system Feature Numbers shall be set as follows in
UL 1023 listed systems:
Table 4: UL 1023 Listed System Settings
Feature No. Feature
xx002 Siren Sound Time
xx003 Entry Delay
xx004 Exit Delay
yy004 Communication Format
xx088 Report Partition Events
xx092 Auto Forced Arming
xx097 Exterior Siren Arming Verifi-
cation
xx102 Exit Delay Reset
xx108 Local Trouble Annunciation
at LTIME.
17036 AC Stable Time
17041 AC Report Delay
17049 RF Supervisory Time
17069 No Phone Line
17072 Enable RF Jam Detect
17073 Automatic Panel Backup Bat-
tery Test Interval
17076 Commercial/Residential
17078 Detect Receiver Failure
17079 Alarm Messages Play at High
Volume
17096 Report System Events
47004 #2-Supervisory Time Zone
Attribute (all sensors)
#4-Hardwire Smoke Verify
Zone Attribute
xx = Two digit partition number.
yy = Two digit non-pager phone number.
Central Station Burglar-Alarm System Units (UL 1610)
Basic system using Commercial Burglary (60-562-01 or
60-562-04) Control Panel, plus:
q Hardwire Magnetic Contact (13-068 or 13-071).
The basic system may also include:
q SuperBus 2000 Commercial RF Transceiver (60-821)
for use with listed wireless signaling devices.
q Wireless Learn Mode Door/Window Sensor (60-362).
q SuperBus 2000 Printer or Automation Module
(60-783) for use with a listed printer.
q SuperBus 2000 Dual Phone Line Module (60-768) for
Commercial Burglary and Home Navigator System
reporting to multiple phone lines.
System Setup and Programming
The system Feature Numbers shall be set as follows in
UL 1610 listed systems:
Feature No.
xx002
xx003
Required Setting
xx004
6 min. minimum
yy004
45 sec. maximum
xx088
60 sec. maximum
xx092
0 Contact ID
xx097
1-On
0-Off
xx098
0-Off
xx102
0-Off
xx108
1-On
17034
90 sec. maximum
17036
6-12 hours
17041
4 hours
17049
0-Off
17069
1-On
17072
1-4 hours
17073
0-Off Residential
17076
1-On
17078
1-On High
17079
1-On
17096
A (set to 4 hrs. in
47004
Feature 17049)
0-No
xx = Two digit partition number.
yy = Two digit non-pager phone number.
Digital Alarm Communicator System Units (UL 1635)
Same as UL 1610 plus:
q A UL Listed Exterior Siren.
Central Station Reporting
The panel has been tested with the following central station
receivers using Contact ID reporting format:
q ITI CS-5000 Central Station Receiver.
q Sur-Gard Central Station Receiver with models
SG-DRL2A and SG-CPM2.
q Radionics Model (D6600).
Table 5: UL 1610 Listed System Settings
Feature
Siren Sound Time
Entry Delay
Exit Delay
Communication Format
Report Partition Events
Auto Forced Arming
Exterior Siren Arming Verifi-
cation
Local Closing Report Verifi-
cation
Exit Delay Reset
Local Trouble Annunciation
at LTIME.
Auto Phone Test Frequency
AC Stable Time
AC Report Delay
RF Supervisory Time
No Phone Line
Enable RF Jam Detect
Automatic Panel Backup Bat-
tery Test Interval
Commercial/Residential
Detect Receiver Failure
Alarm Messages Play at High
Volume
Report System Events
#2-Supervisory Time Zone
Attribute (all sensors)
#4-Hardwire Smoke Verify
Zone Attribute
Special Installation Requirements
Required Setting
16 min., minimum
45 sec., maximum
60 sec., maximum
0 Contact ID
1-On
0-Off
0-Off
1-On
0-Off
1-On
1 Day
90 sec. maximum
6-12 hours
4 hours
0-Off
1-On
1-4 hours
1-Commercial
1-On
1-On High
1-On
A (set to 4 hrs. in
Feature 17049)
0-No
