Number of Attempts
Default = 3
Set the number of times (attempts) the panel will try to dial the
pager phone number.
Setting the Number of Dial Attempts:
Once the item number has been entered, enter the number of dial
attempts (3–10) and press #.
Communication Format
Default = 1 (TAP at 1200 bps PSK)
Select the type of communication format the panel will use when
reporting events to pagers. Consult your paging service provider
for help in setting this option.
Communication Formats:
q
Enter 0 for TAP at 300 bps (FSK).
q
Enter 1 for TAP at 1200 bps (PSK).
Setting the Communication Format
1. Once the item number has been entered, use the choices above
to select a communication format.
2. Press # to apply the new setting.
Communication Character Format
Default = 1 (7/E/1)
Select the character format the panel will use when reporting to
pagers. Consult your paging service provider for help in setting
this option.
Character Formats
q
Enter 0 for 8/N/1.
q
Enter 1 for 7/E/1.
Setting the Character Format
1. Once the item number has been entered, press 0 for 8/N/1
character format (off), or 1 for 7/N/1 character format (on).
2. Press # to apply the setting.
Pager System Reports
Default = 0 (Off)
Select whether or not you want system events reported to pager.
To Turn System Pager Report On/Off:
Once the item number has been entered, enter 1 to turn this setting
on (report), or 0 to turn it off (don't report). Press # to apply the
new setting.
Commercial Burglary and Home Navigator System
zz003
Partition/Area 1 Reports
(Defaults = 0, Phone 25 = 1)
Partition/Area 2 Reports
(Defaults = 0, Phone 26 = 1)
Partition/Area 3 Reports
(Defaults = 0, Phone 27 = 1)
Partition/Area 4 Reports
(Defaults = 0, Phone 28 = 1)
Partition/Area 5 Reports
(Defaults = 0, Phone 29 = 1)
Partition/Area 6 Reports
(Defaults = 0, Phone 30 = 1)
zz004
Partition/Area 7 Reports
(Defaults = 0, Phone 31 = 1)
Partition/Area 8 Reports
(Defaults = 0, Phone 32 = 1)
Select whether or not you want partition/area events to report to
pager(s).
To turn Partition/Area Report On/Off:
1. Once the item number has been entered, enter 1 to turn this
setting on (report), or 0 to turn it off (don't report).
2. Press # to apply the new setting.
* This option setting is available on 8 partition panel types only
(60-562-01 and 60-562-05).
Pager PIN
zz005
Default = None
Enter up to a 15-digit pager PIN. Consult your paging service pro-
vider for help in setting this option.
To Enter a Pager PIN:
1. Enter the desired item number (ex. 25015).
2. Enter up to a 15-digit (0–9) pager PIN.
3. Press # and the touchpad displays the pager PIN.
Pager Message Length
Default = 120 Characters
Set the maximum character length for pager messages. Consult
your paging service provider for help in setting this option.
zz006
Setting Maximum Pager Message Length:
Once the item number has been entered, enter the maximum
pager length (0–255) and press #.
Advanced Phone Settings
&$87,21
Only qualified persons should make changes to advanced
phone settings.
Maximum Ring Cycle Time
Default = 67 Milliseconds
Specify (in milliseconds) the maximum cycle time for the ring
signal.
Setting the Maximum Ring Cycle Time:
1. Once the item number has been entered, specify the maximum
ring cycle time (0–255).
2. Press # to apply the new setting.
Programming the Panel
zz007
zz008
zz009
zz010
zz011*
zz012*
zz013*
zz014*
zz015
zz016
17018
27
