Feature
Problem
Hardwire Sirens/Bells (continued)
Interior bells are not producing sounds.
Hardwire Speakers (Voice)
Speakers are not producing sounds.
Speaker volume too high or low.
Hardwire Zones
Panel does not respond to hardwire zone input.
Lights (See also X-10 Modules, Hardwire Outputs, or 4 Relay Output Module)
Light fixture using X-10 Lamp Module does not work.
Panel
Panel does not power up. Panel LED is off and alphanumeric touchpad display is dark.
No incoming AC voltage at panel terminals 1 and 2.
Commercial Burglary and Home Navigator System
1. Check for 12 VDC between panel terminals 4 and 5 with bell activated (partition/area 1).
2. Check panel main power.
3. Check for correct wiring at the siren and panel terminals.
4. Check interior bell programming.
5. Be sure that there is an interior bell output programmed for each partition/area that is used.
1. Check for correct wiring (and opens or shorts) at the speaker and panel terminals.
2. Check that required capacitor and end of line (EOL) resistor are installed at the speaker.
3. Make sure that voice volume is correctly programmed.
4. Speaker output is used for partition/area 1 only.
1. Make sure that the voice volume is correctly programmed.
2. Check for too many speakers or incorrect speaker impedance.
1. Check that zones are programmed into panel and add if missing.
2. Make sure that zone is set to a restoral-required type or make sure that system is armed to active
level before tripping sensor.
3. If it is an optional 8 Input Module zone, check that the module bus status LED is blinking to
show communication with panel.
4. Check zone programming for proper partition/area setting.
See X-10 Modules feature in this table.
1. Check the AC circuit breaker to be sure the circuit is live.
2. Check that the backup battery is installed correctly, the battery wires are connected, and the AC
power transformer is plugged in.
3. Check for proper panel and transformer wiring.
4. Measure the incoming AC voltage at the panel terminals. The voltage should be about 24 VAC
between panel terminals 1 and 2.
1. Check that AC power transformer is not wired into a switched circuit.
2. Remove AC power from the transformer and disconnect the wires from the transformer and the
panel.
3. Check transformer to panel wire for short or open circuits.
4. Connect the transformer and check for about 24 VAC at the transformer unconnected terminals.
If zero (0) volts, reset the built-in transformer circuit breaker (if it has one) or replace the trans-
former.
Solution
Troubleshooting
