Programming the Panel
Minimum Tone Duration
Default = 3 (30 ms)
Specify the minimum duration of a valid DTMF (touch-tone) tone
in 10 millisecond increments (1–100 x 10 ms). This is the mini-
mum amount of time that a phone number button must be pressed
in order to be valid.
Setting the Minimum Tone Duration:
1. Once the item number has been entered, specify the minimum
tone duration (1–100).
2. Press # to apply the new setting.
Minimum Duration Between Tones
Default = 5 (50 ms)
Specify the minimum duration of pause between DTMF (touch-
tone) tones in 10 millisecond increments (1–100 x 10 ms). This is
the minimum amount of time required between two phone num-
ber buttons being pressed.
Setting the Minimum Duration Between Tones:
1. Once the item number has been entered, specify the minimum
duration between tones (1–100).
2. Press # to apply the new setting.
Minimum Valid Ring Cycles
Default = 2 Cycles
Specify the minimum number of cycles in a valid ring.
Setting the Minimum Valid Ring Cycles:
1. Once the item number has been entered, specify the minimum
number of cycles (0–255).
2. Press # to apply the new setting.
Valid Ring Bursts
Default = 1 Burst
Specify the number of ring bursts in a valid ring.
Setting the Number of Ring Bursts:
1. Once the item number has been entered, specify the number
of ring bursts (1–5).
2. Press # to apply the new setting.
Valid Ring at Beginning or End of Ring Burst
Default = 0 (Off)
Selects if a ring is considered valid at the beginning of the ring
burst or at the end of the ring burst.
Setting Valid Ring at Beginning or End of Cycle:
Once the item number has been entered, enter 1 or 0. Press # to
apply the new setting.
28
17031
Maximum Ring Burst Duration
Default = 250 (2500 ms)
Specify the maximum duration of a valid ring burst in 10 ms
increments (3–300 x 10 ms).
Setting the Maximum Ring Burst Duration:
1. Once the item number has been entered, specify the maximum
ring burst duration (3–300).
2. Press # to apply the new setting.
Minimum Ring Burst Duration
Default = 40 (400 ms)
17032
Specify the minimum duration of a valid ring burst in 10 ms
increments (3–300 x 10 ms).
Setting the Minimum Ring Burst Duration:
1. Once the item number has been entered, specify the minimum
ring burst duration (3–300).
2. Press # to apply the new setting.
Maximum Duration Between Ring Bursts
Default = 0
Specify the maximum duration between valid ring bursts in 10
millisecond increments (0–300 x 10 ms).
17054
Setting the Maximum Duration Between Ring Bursts:
1. Once the item number has been entered, specify the maximum
duration between ring bursts (0–300).
2. Press # to apply the new setting.
Minimum Duration Between Ring Bursts
Default = 0
Specify the minimum duration between valid ring bursts in 10
17055
millisecond increments (0–300 x 10 ms).
Setting the Minimum Duration Between Ring Bursts:
1. Once the item number has been entered, specify the minimum
duration between ring bursts (0–300).
2. Press # to apply the new setting.
Maximum Time Between Rings
Default = 450 (4500 ms)
17091
Specify the maximum amount of time allowed between valid
rings in 10 millisecond increments (100–999 x 10 ms).
Setting the Maximum Time Between Rings:
1. Once the item number has been entered, specify the maximum
time between rings (100–999).
2. Press # to apply the new setting.
Commercial Burglary and Home Navigator System
17020
17019
17022
17021
17024
