Non X-10 Output 1 (menu output 33)
Non X-10 Output 2 (menu output 34)
Non X-10 Output 3 (menu output 35)
Non X-10 Output 4 (menu output 36)
Non X-10 Output 5 (menu output 37)
Non X-10 Output 6 (menu output 38)
Non X-10 Output 7 (menu output 39)
Non X-10 Output 8 (menu output 40)
Default = 0 (None)
There are 40 menu outputs per partition/area. The first 32 are X-
10 outputs, the last 8 are non X-10 outputs. All X-10 outputs
(menu outputs 1-32) are automatically linked to X-10 devices.
Non X-10 outputs (menu outputs 33-40) must be linked to a pro-
grammable output in order to control a light or device.
Note
All menu outputs must be programmed (learned) into the
panel before they will function. See "Programmable Out-
put Settings" on page 36 for more information.
Linking Non X-10 Outputs:
1. Enter the item number for the desired non X-10 output.
2. Enter the desired programmable output number (1–100), then
press # to confirm the selection.
Light Access Code Enable
Default = 0 (Off)
If on, users must enter a valid access code before controlling
lights. If off, an access code is not required for light control.
Turning Light Access Code On/Off:
Once the item number has been entered, enter 1 for on (access
code required), or 0 for off. Press # to apply the new setting.
Device Access Code Enable
Default = 0 (Off)
If on, users must enter a valid access code before controlling
devices. If off, an access code is not required for device control.
Turning Device Access Code On/Off:
Once the item number has been entered, enter 1 for on (access
code required) or 0 for off. Press # to apply the new setting.
Latchkey Access Code Enable
Default = 0 (Off)
If on, users must enter a valid access code before accessing the
Latchkey setting. If off, an access code is not required to access
the Latchkey setting. For more information on Latchkey, please
see the User's Manual.
Turning Latchkey Access Code On/Off:
Once the item number has been entered, enter 1 for on (access
code required) or 0 for off. Press # to apply the new setting.
Commercial Burglary and Home Navigator System
Reporting Settings
xx049
Report Partition/Area Events
xx050
Default = 1 (On)
xx051
If on, the panel will report partition/area events to the central sta-
xx052
tion.
xx053
xx054
Turning Partition/Area Event Reporting On/Off:
xx055
Once the item number has been entered, enter 1 to turn partition/
xx056
area event reporting on or 0 turn reporting off. Press # to apply the
new setting.
Cancel Event Cancels Report
Default = 1 (On)
If on, the panel will cancel the sending of an alarm report (to cen-
tral station) if the event is canceled before the alarm reporting
delay (xx013, xx012, or xx014) expires.
Turning Cancel Event Cancels Report On/Off:
Once the item number has been entered, enter 1 to turn the setting
on (canceled event cancels report) or 0 to turn it off. Press # to
apply the new setting.
Print Partition/Area Events
xx069
Default = 1 (On)
If on, the panel will print partition/area events on a local printer.
To Print Partition/Area Events:
Once the item number has been entered, enter 1 (on) to enable
printing of partition/area events or 0 (off) to disable printing of
partition/area events. Press # to apply the new setting.
Panic Report Delay
xx070
Default = 05 Seconds
This setting allows you to specify the length of time (in seconds)
between the time a panic alarm condition is detected, and a panic
report is sent to the central station. This allows users time to can-
cel the report of a false alarm if setting xx089 is on.
Specifying the Panic Report Delay:
Once the item number has been entered, enter the number of sec-
onds (1–120) you wish the panel to wait before sending a panic
report. Press # to apply the new setting.
xx071
Alarm Report Delay
Default = 05 Seconds
This setting allows you to specify the length of time (in seconds)
between the time a non-panic and non-fire alarm condition is
detected, and a report is sent to the central station. This allows
users time to cancel the report of a false alarm if setting xx089 is
on.
Specifying the Alarm Report Delay:
Once the item number has been entered, enter the number of sec-
onds (1–120) you wish the panel to wait before sending a report.
Press # to apply the new setting.
Programming the Panel
xx088
xx089
xx091
xx012
xx013
19
