is the "The operating system has halted. Please press any key to reboot" message.

Wait at least 60 seconds after first seeing this message before following the

instructions in Step

3. Attach the grounding strap to your bare wrist and to a site ESD point.

4. Disconnect power to the device by performing one of the following tasks:

AC power supply—If the AC power source outlet has a power switch, set it to the OFF (O) position.

If the AC power source outlet does not have a power switch, gently pull out the plug end of the

power cord connected to the power source outlet.

DC power supply—Switch the circuit breaker on the panel board that services the DC circuit to the

OFF position.

5. Remove the power source cable from the power supply faceplate:

AC power supply—Remove the power cord from the power supply faceplate by detaching the power

cord retainer and gently pulling out the socket end of the power cord connected to the power supply

DC power supply—Remove the screws securing the ring lugs attached to the power source cables

to the power supply using the screwdriver, and remove the power source cables from the power

supply. Replace the screws on the terminals and tighten them.

Removing a QFX5110 from a Rack

If you need to relocate an installed QFX5110, use the procedure described in this topic.

The final output of any version of the request system halt command

to remove power from device.
