Quick Start Guide
QFX5100-48T
IN THIS GUIDE
Step 1: Begin | 1
Step 2: Up and Running | 4
Step 3: Keep Going | 6
Step 1: Begin
IN THIS SECTION
Mount the QFX5100-48T | 2
Connect Power to the Switch | 3
To install and configure a Juniper Networks QFX5100 Switch, you need:
Electrostatic discharge (ESD) grounding strap (not provided)
One pair of front mounting-rails (provided)
One pair of rear mounting-blades (provided)
Twelve screws to secure the mounting-rails and mounting-blades to the chassis (provided)
Eight screws to secure the chassis and mounting-blades to the rack (not provided)
Screwdriver appropriate for your rack mounting screws (not provided)
Two power cords with plugs appropriate for your geographical location (provided)
RJ-45 cable and RJ-45 to DB-9 serial port adapter (provided)
