Upgrading R5si/R6si to an Avaya DEFINITY Server R
EPN running Avaya MultiVantage Software
Remove the Existing Control Cabinet
Because the control cabinet is at the bottom of the port network, you must first
dismantle the cabinet stack. Disconnect all the power, ground, TDM, ICC, and
connector cables.
1. Remove the cabinet clip between each cabinet or front earthquake plate as
provided.
2. Remove the rear ground plate.
3. Remove the port cabinets from the stack.
!
4. If the system is duplicated, remove the control cabinet in position B. It is not
reused.
5. If the basic control cabinet in position A is earthquake mounted, remove
and retain the hardware securing the cabinet to the floor.
6. Remove the basic control cabinet. It is not reused.

Install the EPN

Unpack and Install Expansion Control Cabinet
1. Unpack and inspect the J58890N Expansion Control Cabinet.
2. Position the expansion control cabinet at the desired location.
3. Reinstall the earthquake mounting hardware, if required.
Install Port Cabinets
1. If a stacked system, replace the port cabinets into their proper positions.
Install Circuit Packs
1. Replace the circuit packs and power supplies in port cabinets C and D if
they were previously removed.
2. Using the label on the front of the carrier and the annotated list of all the
circuit packs installed in the existing cabinets, install the control circuit
packs into the new expansion control cabinet.
4-20
Issue 5 October 2002
CAUTION:
A port cabinet may weigh as much as 125 pounds (567 kg). Use
lifting precautions.
NOTE:
If the Release 5/6si SCC was duplicated, then the J58890M Control
Cabinet can be replaced by a J58890H Port Cabinet in position B.
