Interconnect Port Networks with Fiber Optic Cabling
Figure Notes
1. Lightwave Transceiver
2. To EPN1 Carrier A Slot 2A02
3. To EPN2 Carrier A Slot 3A02
4. To EPN1 Carrier B Slot 2B03
Figure 5-31. Fiber Optic Connections EPN1 to EPN2
For Either 1 or 2 Fiber-Remoted Expansion Port Networks
1. Behind control carrier A of PPN cabinet 1 (see
5-34):
555-233-115
RX TX
4 3
RX TX
2 1
Install a lightwave transceiver on the cable connector at slot 1A01.
Connect a fiber optic cable to the transceiver just installed.
Route the cable to the cable tray and down, out of the cabinet,
through the cable manager to the PDS cross-connect facility.
Connect the fiber cable to the lightguide interconnect unit provided.
Carefully attach the fiber optic cable (with cable ties) to the wall of
the cable tray at the built-in cable tie positions.
4
2
5. To EPN2 Carrier B Slot 3B03
6. Fiber Optic Cable
7. TX Connector
8. RX Connector
Figure 5-33
Issue 5 October 2002
3
1
cydff06 CJL 103196
through Figure
5-121
