Install the MCC1 Cabinets

Remove Emergency Transfer Ground Wire

1. If the MCC1 is being installed while the present system is in service:
a. Connect a 10 AWG (#25) (2.6 mm
b. Route the other end of the wire to an approved ground and connect.
2. If the present system was removed to make room for the MCC1 cabinet:
a. Disconnect the 10 AWG (#25) (2.6 mm

Power-Up the MCC1 PPN

1. Insert the Avaya MultiVantage Software on removable media into the
optical drive.
2. Power up the MCC1 cabinet and allow the system to boot up completely.

Install the License File

Pre-installation
1. Type save translation and press
After the translations have been copied (about 10 minutes), the system
returns an error code, which must be a zero; otherwise, the translations are
not copied.
2. Type reset system 3 and press
Wait until the system has completely reset before continuing.
3. If the system has IP endpoints registered, unplug the Ethernet cable from
the TN799 (C-LAN) circuit pack.
This disconnects (unregisters) all IP endpoints.
4. Type set time and press
Ensure that the system date and time are set correctly.
555-233-115
connecting block or pin 49 of the CAP (cable access panel)
associated with the emergency transfer panel.
the connecting block or pin 49 of the CAP (cable access panel).
Enter
2
) wire to either pin 49 of the
2
) wire (installed earlier) from
.
Enter
.
Enter
.
