Adding or Removing Cabinet Hardware

Add Speech Synthesis

The Speech Synthesizer circuit pack is required when the Voice Message
Retrieval, Automatic Wakeup, or Do Not Disturb features are activated. The circuit
pack does not require administration.
1. Determine the port assignment of the Speech Synthesizer circuit pack
being added.
2. Install the Speech Synthesizer circuit pack in the designated carrier slot.

Add Code Calling Access

The tones for the Code Calling feature are generated by the Tone-Clock circuit
packs in the port networks.
1. Install an Auxiliary Trunk circuit pack or a Speech Synthesizer circuit pack
and connect for Loudspeaker Paging. The Code Calling Access feature
shares the same ports as Loudspeaker Paging. An Auxiliary Trunk circuit
pack provides 4 ports for Loudspeaker Paging and Code Calling Access.
2. Administer the form listed under "Code Calling Access" in Administrator's
Guide for Avaya MultiVantage Software.

Add Pooled Modem

Modem pooling supports two types of conversion resources: integrated and
combined.
An integrated conversion requires a Pooled Modem circuit pack for each 2
conversion resources provided.
A combined conversion requires a port of a TN745B or TN2136 Digital Line circuit
pack and a port of either an 8-port TN742, TN769, a 16-port TN746B, or a 24-port
TN793/B, TN2793/B Analog Line circuit pack for each conversion resource
provided.
The pooled modem requires a WP90110 L7 power supply. Although integrated
conversion can use either the L5 or L7, the combined only works with an L7.
!
CAUTION:
The L5 and L7 power supplies look identical. Check the label to be sure you
have the L7 before installing.
Determine the port assignment of the circuit packs to be added (if required).
3. Install the appropriate circuit packs in assigned carrier slot (if required).
4. For Paradyne 3800 series modems:
a. Type AT&F&D2&S4\D3S2=128x7V2S7=60S85=1 and press
b. Type ATY0S10=100S78=2M0E0\N1&W and press
5. For other types of modems, refer to the vendor's documentation.
