Installing a 3150/3170 Channel Service Unit

Installing a 3150/3170
Channel Service Unit
1. Install the CSU as shown in
DS1 converter), use a Y-cable to connect the Avaya Media Gateway to the
quad cable.
cables.
Figure 7-18
the CSU, through the H600-307 network cable, and to the network
interface through the smart jacks. The quad cable provides up to four
connections using a 15-pin connector that plugs into the DTE jack on each
CSU. The H600-348 quad cable may require an adapter cable.
Figure Notes
1. H600-348 quad cable
2. 15-pin male "D" connectors (to DTE jacks on CSU)
3. Channel service unit (CSU)
4. H600-307 cable (RJ-48C to RJ-48C)
Figure 7-18. 3150/3170 Channel Service Unit Connections
555-233-115
Figure
Table 7-17 shows the Y-cable lengths. Be sure to label all
shows a typical connection from the H600-348 Quad cable to
POWER AUX PORT COM PORT MODEM
DTE
POWER AUX PORT COM PORT MODEM
DTE
POWER AUX PORT COM PORT MODEM
DTE
POWER AUX PORT COM PORT MODEM
DTE
7-18. For some installations (such as a
NETWORK
NETWORK
NETWORK
NETWORK
3150csu RBP 062696
5. Network interface
6. Smart jack (if provided)
7. Cable A
8. Cable B
Issue 5 October 2002
9. Cable C
10. Cable D
7-105
