Adding or Removing Cabinet Hardware
2. Set the Type field to ethernet.
3. Set the Port field to correspond to the circuit pack location.
In the example above, 1b0333 means Cabinet 1, Carrier B, Slot 3, Port 33.
4. Set the Link field to an unassigned or next-available link number.
5. Set the Network uses 1's for Broadcast Address? field according to the
your network requirements.
6. Type a unique name in the Name field.
7. Press
8. If your system uses IP routing, continue with the
Otherwise, go to the
add ip-route
Use this command to administer IP routes to the TN2501AP circuit pack. This
administration is optional.
Test the IP connections
Use the ping and status link commands to test the new IP connections that you
have administered.
Add ISDN—PRI
North American
1. Install a TN767E (or later) DS1 or a TN464F DS1/E1 circuit pack for a
signaling link and up to 23 ISDN — PRI Trunk Group members.
2. Install a Tone-Clock circuit pack to provide synchronization for the DS1
circuit pack.
International
1. Install a TN464C (or later) DS1/E1 circuit pack for the assignment of the 2
signaling channels and up to 30 ISDN — PRI Trunk Group members. Each
E1 span provides 32 ports.
2. Install a Tone-Clock circuit pack to provide synchronization for the DS1/E1
circuit pack.
7-48
Issue 5 October 2002
NOTE:
The port number (final two digits) is always 33 for the TN2501AP
circuit pack.
to save your changes.
ENTER
Test the IP connections
add ip-route section.
section.
