Administer Fiber Links
Fiber Link Administration Form
This form administers fiber links, each of which is identified by a fiber number.
NOTE:
Fiber link administration only applies to R5r and later configurations.
Port networks (PNs) are connected via direct fiber link connections or through a
center stage switch (CSS) to provide the interconnection of port networks required
for voice/data information transfer. The CSS is composed of "switch nodes" that
can be interconnected in one or two levels to provide Port Network Connectivity
(PNC). The CSS provides circuit-switched connectivity for voice and data
communications as well as packet-switched connectivity. Fiber link administration
permits an administration of translation data associated with a switch connection
(such as optical fiber, metallic cable, or DS1CONV circuit packs and DS1 facility
links between two endpoints). The two fiber endpoints can be:
An expansion interface (EI) circuit pack
A switch node interface (SNI) circuit pack
Administration commands
Use the following commands to administer the Fiber Link Administration form.
Action
add
change
display
list
remove
1. Brackets [ ] indicate the qualifier is optional. Single
quotes (' ') indicate the text inside the quote must
be entered exactly as shown or an abbreviated
form of the word may be entered.
555-233-115
NOTE:
Only one administrative terminal can administer fiber links at a time;
others can display fiber link information.
Object Qualifier
fiber-link link number or ['next']
fiber-link link number
fiber-link link number
fiber-link link number
fiber-link link number
1
Issue 5 October 2002
A-7
