Upgrading a Multicarrier G2 Universal Module to Avaya
DEFINITY Server R EPN running Avaya MultiVantage
Software
Figure Notes
1. Cabinet 1 Processor Port Network
2. Cabinet 2 Expansion Port Network 1
Figure 5-24. High Reliability with Two or Three Port Networks
5-112
Issue 5 October 2002
3. Cabinet 3 Expansion Port
Network 2
555-233-115
