Add the Fiber Optic Cable
17. Review the information displayed in the report.
If any of the data are incorrect, contact the DBA Group (1-800-248-1234,
selecting prompt, 2, prompt 6, then prompt 2) immediately for assistance.
18. Save the DEFINITY Upgrade Registration Report in a file for future
reference or print the report and keep the copy.
Add the Fiber Optic Cable
This chapter details the installation of the fiber optic cable using the DEFINITY
fiber optic pass-thru kit for Multicarrier Cabinets (MCC1) only. This kit (comcode
848029278) provides the equipment necessary to install the fiber optic connectors
and associated cabling.
Unpack and Inspect
1. Verify the equipment received. See
vary in appearance and may ship in separate packages.
2. See
2
4
Figure Notes
1. Pass-thru Tool
2. SC-SC Fiber Optic Adapter
3. ST-SC Fiber Optic Adapter
4. Fiber Optic Cable
Figure 6-13. Fiber Pass-Thru Kit Equipment
555-233-115
Table 6-3
for a list of part Comcodes.
3
5
Figure
6-13. Actual equipment may
1
6
8
5. Fiber Optic Cable Disconnect Label
6. I/O Connector Adapter Bracket
7. Cable Tie
8. Cable Tie Mount
Issue 5 October 2002
7
indapkit RPY 012398
6-33
