Install a New EPN Cabinet in an Existing System

Install a New EPN Cabinet in an
Existing System
Figure 6-38
normally positioned adjacent to the PPN cabinet but may be located remotely in a
different room or a different building.
Port Carrier "C"
Control Carrier "A"
Port Carrier "D"
Power Distribution
Figure 6-38. Typical Multicarrier EPN Cabinet
1. Uncrate and position the cabinet as instructed at the beginning of this
chapter.
2. Install earthquake protection.
555-233-115
shows a typical multicarrier EPN cabinet. Each EPN cabinet is
Port Carrier "B"
Fans 2
Port Carrier "E"
3
0075_0 RBP 080196
