Avaya DEFINITY Server R Manual page 270

Upgrading a Multicarrier G2 Universal Module to Avaya
DEFINITY Server R EPN running Avaya MultiVantage
Software
12. Connect the loose end of the TDM/LAN cable (between the "A" and "D"
carriers) to the pin-field block marked "TDM" on the right side of the "A"
carrier (see
connected to the "D" carrier when the old carrier was removed.
13. Connect the loose end of the TDM/LAN cable (between the "B" and "C"
carriers) to the pin-field block marked "TDM" on the right side of the "B"
carrier. The other end remained connected to the "C" carrier when the old
carrier was removed.
14. Install the TDM/LAN cable between the "A" and "B" carriers. The cable is
connected to the "A" and "B" carriers at the pin-field blocks marked "TDM"
on the left side of each carrier.
Table 5-17. TDM/LAN Connections
"J" Number
J58890BB-1
J58890BB-2
J58890BB-3
J58890AF
15. On port carrier J58890BB-1, connect the TDM cable or the TDM terminator
to Slot 02. On port carriers J58890BB-2 and J58890BB-3, connect the
TDM cables or the TDM terminator to Slot 01. If the port carrier has
J58890BB-1 and J58890BB-2 printed on it, treat it as a J58890BB-1.
5-78
Issue 5 October 2002
Figure 5-13 and Table
Carrier Type
Port
Port
Port
EPN Control "A"
5-17). The other end remained
LHS Slot RHS Slot
21
21
21
21
02
01
01
02
555-233-115
