SLM-7650 Satellite Modem
Operation
Key
[ENTER]
[CLEAR]
[←] and [→]
[↑] and [↓]
3.2

Front Panel Operation

3.2.1

Front Panel Menu Operation

When the modem is first powered ON, the sign-on message for the menu system
displays. This sign-on message is also displayed when the [CLEAR] key is pressed
repeatedly from anywhere within the menu system. The sign-on message displays the
following information:
•
•
An overview of the first three layers in modem menu system is shown in Figure 3-3.
Function Select is the main level of the menu system. To access this level from the sign-
on message, press any of the arrow keys. The modem control and monitor parameters are
accessed from the following Function Select menus:
•
•
•
•
•
•
Press [←] or [→] to move from one selection to another. When line 2 displays the desired
function, select that level by pressing [ENTER]. After entering the appropriate functional
level, press [←] or [→] to move to the desired function.

Table 3-2. Keypad Functions

This key is used to select a displayed function, or to execute a modem
configuration change.
This key is used to back out of a selection, or to cancel a configuration change,
which has not been executed using [ENTER]. Pressing [CLEAR] generally
returns the display to the previous selection.
These keys are used to move to the next selection, or to move the cursor for
certain functions.
These keys are used primarily to change configuration data (numbers), but are
also used at times to move from one section to another.
Line 1 is the modem model number and type.
Line 2 is the version number of the M&C firmware.
Configuration
Monitor
Faults/Alarms
Stored Faults/Alarms
Remote Automatic Uplink Power Control (AUPC)
Utility
Function
3-3
Revision 4
MN/SLM7650.IOM
