SLM-7650 Satellite Modem
Remote Control Specifications
DDO/IDI
Command:
Loopback
Response:
Status:
Response:
Drop
Command:
Channels
Response:
Assignment
Status:
Response:
Bulk Drop
Command:
Channels
Response:
Assignment
Status:
Response:
Insert
Command:
Channels
Response:
Assignment
Status:
Response:
<add/DIL_xxx'cr'
>add/DIL_xxx'cr''lf']
<add/DIL_'cr'
>add/DIL_xxx'cr''lf']
<add/DCA_dd;cc'cr'
>add/DCA_dd;cc'cr''lf']
<add/DCA_dd'cr'
>add/DCA_dd;cc'cr''lf']
<add/BDCA_dd;cc_dd;cc_dd;cc... 'cr'
>add/BDCA_dd;cc_dd;cc_dd;cc...'cr''lf']
<add/BDCA_'cr'
>add/BDCA_dd;cc_dd;cc_dd;cc...'cr''lf']
<add/ICA_ii;cc'cr'
>add/ICA_ii;cc'cr''lf']
<add/ICA_ii'cr'
>add/ICA_ii;cc'cr''lf']
Where: xxx = ON or OFF.
Where:
dd = 1 to n (over the satellite drop channel), where n =
modulator data rate divided by 64 kbit/s.
cc = 1 to 24 (terrestrial channel number for T1 data formats).
cc = 1 to 31 (terrestrial channel number for E1 data
formats).
Notes:
1.
This command is not valid when the drop data
format is specified as E1CAS, and the modulator
data rate is set to 1920.0 kbit/s
Where:
dd = 1 to n (over the satellite drop channel), where n =
modulator data rate divided by 64 kbit/s.
cc = 1 to 24 (terrestrial channel number for T1 data formats).
cc = 1 to 31 (terrestrial channel number for E1 data
formats).
Notes:
1.
The status response returns programming
information for 1 to n drop channels.
2.
This command is not valid when the drop data
format is specified as E1CAS, and the modulator
data rate is set to 1920.0 kbit/s
Where:
ii = 1 to n (over the satellite insert channel), where n =
demodulator data rate divided by 64 kbit/s.
cc = 1 to 24 (terrestrial channel number for T1 data formats).
cc = 1 to 31 (terrestrial channel number for E1 data
formats).
cc = 0 (if no insert is desired for the specified insert
channel).
Notes:
1.
This command is not valid when the insert data
format is specified as E1CAS, and the
demodulator data rate is set to 1920.0 kbit/s
A–17
Revision 4
MN/SLM7650.IOM
