SLM-7650 Satellite Modem
Operation
Menu Item
ASYNC TX
ASYNC RX
ASYNC COMM TYPE
ASYNC CONNECTOR
Programs the baud rate settings and interface format of ASYNC overhead in the
modem.
To change the ASYNC overhead baud rate (110 to 38400 bps), press [ENTER]. Press
[
] or [
] to position the cursor over the baud rate parameter. Press [
←
→
one of the following baud rates (bps): 110, 150, 300, 600, 1200, 2400, 4800, 9600,
19200, 38400. Once the desired baud rate is displayed, press [ENTER] to set the
baud rate.
To change the ASYNC overhead interface format of the modem is displayed press
[ENTER]. Press [
] or [
←
→
Press [
↑
] or [
↓
] to scroll through the available interface formats. Once the desired
format is displayed, press [ENTER] to set the baud rate.
The number of data bits, parity, and stop bits is selectable. Available formats are: 7
data bits, Even parity, and 1 stop bits (7E1); 7 data bits, Odd parity, and 1 stop bits
(7O1), 7 data bits, No parity, and 1 stop bit (7N1), 7 data bits, Even parity, and 2 stop
bits (7E2); 7 data bits, Odd parity, and 2 stop bits (7O2); 7 data bits, No parity, and 2
stop bit (7N2), 8 data bits, Even parity, and 1 stop bits (8E1); 8 data bits, Odd parity,
and 1 stop bits (8O1); 8 data bits, No parity, and 1 stop bit (8N1), 8 data bits, Even
parity, and 2 stop bits (8E2); 8 data bits, Odd parity, and 2 stop bits (8O2);8 data bits,
or No parity, and 2 stop bit (8N2)
Programs the baud rate settings and interface format of RX ASYNC overhead in the
modem.
To change the RX ASYNC overhead baud rate (110 to 38400 bps), press [ENTER].
Press [
←
] or [
→
] to position the cursor over the baud rate parameter. Press [
select one of the following baud rates (bps): 110, 150, 300, 600, 1200, 2400, 4800,
9600, 19200, 38400. Once the desired baud rate is displayed, press [ENTER] to set
the baud rate.
To change the RX ASYNC overhead interface format of the modem is displayed press
[ENTER]. Press [
←
] or [
→
Press [
↑
] or [
↓
] to scroll through the available interface formats. Once the desired
format is displayed, press [ENTER] to set the baud rate.
The number of data bits, parity, and stop bits is selectable. Available formats are: 7
data bits, Even parity, and 1 stop bits (7E1); 7 data bits, Odd parity, and 1 stop bits
(7O1), 7 data bits, No parity, and 1 stop bit (7N1), 7 data bits, Even parity, and 2 stop
bits (7E2); 7 data bits, Odd parity, and 2 stop bits (7O2); 7 data bits, No parity, and 2
stop bit (7N2), 8 data bits, Even parity, and 1 stop bits (8E1); 8 data bits, Odd parity,
and 1 stop bits (8O1); 8 data bits, No parity, and 1 stop bit (8N1), 8 data bits, Even
parity, and 2 stop bits (8E2); 8 data bits, Odd parity, and 2 stop bits (8O2);8 data bits,
or No parity, and 2 stop bit (8N2).
Programs the ASYNC COMM type as EIA-232, EIA-485 (2-Wire),
or EIA-485 (4-wire).
On entry, press an arrow key to make the selection. Press [ENTER] to execute the
change.
Selects interface connector to use for ASYNC Channel, J2 (9 pin) or J6 (50 pin).
3-17
Specifications/usage
] to position the cursor over the interface format parameter.
] to position the cursor over the interface format parameter.
Revision 4
MN/SLM7650.IOM
] or [
] to select
↑
↓
↑
] or [
↓
] to
