SLM-7650 Satellite Modem
Operation
3.5
Modes of Operation
The modem has multiple modes of operation that are selectable from any of the control
interfaces. These modes simplify the configuration of the modem by setting up default
values that are consistent with network requirements. The modes of operation are
selected in the Utility: Modem Type menu (Paragraph 3.4.6.5).
When a mode of operation is selected, the modem will be configured for a particular set
of default operating parameters. Certain menus will be displayed, blanked, or disabled
based on the requirements for that particular operating mode.
The following paragraphs will detail each of the modes of operation and provide a table
with the default parameters.
3.5.1
7650-00 Operation
The 7650-00 mode of operation is the basic OM-73 interoperability mode. This mode is
compatible with MIL-STD-188-165 Rev. – and Rev. A with some extended capability.
The additional capability includes 8-PSK and 16-QAM. This mode is similar to, and
compatible with, the 8650-00 mode in the Comtech EF Data SLM-8650 satellite modem.
3-34
Revision 4
MN/SLM7650.IOM
