SLM-7650 Satellite Modem
Remote Control Specifications
Transmit Data Command:
Fault Response:
Status:
Response:
Receive Data Command:
Fault Response:
Status:
Response:
Transmit Data Command:
Phase Response:
Status:
Response:
Receive Data Command:
Phase Response:
Status:
Response:
RTS TX-IF Command:
Control Mode Response:
Status:
Response:
Interface Command:
Coding Response:
Format
Transmit Status:
Response:
Interface Command:
Coding Response:
Format
Receive Status:
Response:
Interface Command:
Service Response:
Channel Level
Status:
Response:
Drop Data Command:
Format Response:
Status:
Response:
Insert Data Command:
Format Response:
Status:
Response:
<add/TDF_xxxx'cr'
>add/TDF_xxxx'cr''lf']
<add/TDF_'cr'
>add/TDF_xxxx'cr''lf']
<add/RDF_xxxx'cr'
>add/RDF_xxxx'cr''lf']
<add/RDF_'cr'
>add/RDF_xxxx'cr''lf']
<add/TDP_xxx'cr'
>add/TDP_xxx'cr''lf']
<add/TDP_'cr'
>add/TDP_xxx'cr''lf']
<add/RDP_xxx'cr'
>add/RDP_xxx'cr''lf']
<add/RDP_'cr'
>add/RDP_xxx'cr''lf']
<add/RTSM_xxx'cr'
>add/RTSM_xxx'cr''lf']
<add/RTSM_'cr'
>add/RTSM_xxx'cr''lf']
<add/ICFT_xxxx'cr'
>add/ICFT_xxxx'cr''lf']
<add/ICFT_'cr'
>add/ICFT_xxxx'cr''lf']
<add/ICFR_xxxx'cr'
>add/ICFR_xxxx'cr''lf']
<add/ICFR_'cr'
>add/ICFR_xxxx'cr''lf']
<add/ISCL_xxx_nnn'cr'
>add/ISCL_xxx_nnn'cr''lf']
<add/ISCL_xxx'cr'
>add/ISCL_xxx_nnn'cr''lf']
<add/DDF_xxxxx'cr'
>add/DDF_xxxxx'cr''lf']
<add/DDF_'cr'
>add/DDF_xxxxx'cr''lf']
<add/IDF_xxxxx'cr'
>add/IDF_xxxxx'cr''lf']
<add/IDF_'cr'
>add/IDF_xxxxx'cr''lf']
Where: xxxx = NONE, DATA, or AIS.
Where: xxxx = NONE, DATA, or AIS.
Where: xxxx = NRM (normal data phasing) or INV (inverted
data phasing).
Where: xxx = NRM (normal data phasing) or INV (inverted
data phasing).
Where: xxx = ON or OFF.
This command configures the modem for the RTS TX-IF
control mode. If 'ON' is selected, the TX-IF output will only
be turned on if the incoming RTS signal is asserted (also the
TX-IF output has to be programmed ON and no major
modulator faults are present). If 'OFF' is selected, the TX-IF
output will operate normal ignoring the RTS signal.
Where: xxxx = AMI, HDB3, B6ZS, or B8ZS.
Where: xxxx = AMI, HDB3, B6ZS, or B8ZS.
Where:
xxx = TX1, TX2, RX1, or RX2 (service channel designator).
nnn = -6 to +8, in steps of 2 (service channel level in dB).
Where: xxxxx = T1, T1ESF, E1CCS, or E1CAS.
Where: xxxxx = T1, T1ESF, E1CCS, or E1CAS.
A–16
Revision 4
MN/SLM7650.IOM
