SLM-7650 Satellite Modem
Remote Control Specifications
Common
Command:
Equipment
Response:
Status
Interface
Command:
Alarms
Response:
(Backward
Alarm)
Status
<add/CES_'cr'
>add/CES_'cr'
M&C_xxx'cr'
BAT_xxx'cr'
-12V_xxx'cr'
+12V_xxx'cr'
+5V_xxx'cr'
+3.3V_xxx'cr'
+2.5V_xxx'cr'
+1.8V_xxx'cr'
TEMP_xxx'cr'
PLL_xxx'cr'
ACT_xxx'cr'
SFLT_xx'cr''lf']
<add/IAS_'cr'
>add/IAS_'cr'
TXBWA1_xxx'cr'
TXBWA2_xxx'cr'
TXBWA3_xxx'cr'
TXBWA4_xxx'cr'
RXBWA1_xxx'cr'
RXBWA2_xxx'cr'
RXBWA3_xxx'cr'
RXBWA4_xxx'cr'
SFLT_xx'cr''lf']
Controller Module (OK/FLT)
Battery/Clock (OK/FLT)
-12 Volt Level (OK/FLT)
+12 Volt Level (OK/FLT)
+5 Volt Level (OK/FLT)
+3.3 Volt Level (OK/FLT)
+2.5 Volt Level (OK/FLT)
+1.8 Volt Level (OK/FLT)
Temperature (OK/FLT)
Modem Reference PLL (OK/FLT)
Modem Reference Activity (OK/FLT)
Number of stored faults logged (0 to 10)
The common equipment status command causes a block
of data to be returned which indicates the status of the
common equipment.
TX Backward Alarm 1 (OK/FLT)
TX Backward Alarm 2 (OK/FLT)
TX Backward Alarm 3 (OK/FLT)
TX Backward Alarm 4 (OK/FLT)
RX Backward Alarm 1 (OK/FLT)
RX Backward Alarm 2 (OK/FLT)
RX Backward Alarm 3 (OK/FLT)
RX Backward Alarm 4 (OK/FLT)
Number of stored faults logged (0 to 10)
A–32
Revision 4
MN/SLM7650.IOM
