SLM-7650 Satellite Modem
Operation
Operating Mode
7650-02, Async
7650-02, Async
7650-02, Async
7650-02, Async
7650-02, Async
7650-02, Async
7650-02, Async
IDR
IDR
IDR
IDR
IDR
IDR
IDR
IDR
IDR
IDR
IDR
IDR
IDR/IESS310 = ON
IBS
IBS
IBS
IBS
IBS/IESS310 = ON
IBS-309
IBS-309
VSAT-IBS
VSAT-IBS
VSAT-IBS
VSAT-IBS/ IESS310 = ON
Modulation/Coding
QPSK, OQPSK 1/2
QPSK, OQPSK 3/4
QPSK, OQPSK 7/8
8-PSK 2/3
8-PSK 5/6
16-QAM 3/4
16-QAM 7/8
QPSK 1/2
QPSK 3/4
QPSK 1/2
QPSK 3/4
QPSK 1/2
QPSK 3/4
QPSK 1/2
QPSK 3/4
QPSK 1/2
QPSK 3/4
QPSK 1/2
QPSK 3/4
8-PSK 2/3
QPSK 1/2
QPSK 3/4
QPSK 1/2
QPSK 3/4
8-PSK 2/3
QPSK 1/2
QPSK 3/4
BPSK 1/2
QPSK 1/2
QPSK 3/4
8-PSK 2/3
FEC/Overhead Type
Viterbi and R-S, Async
Viterbi and R-S, Async
Viterbi and R-S, Async
Trellis and R-S, Async
Trellis and R-S, Async
Viterbi and R-S, Async
Viterbi and R-S, Async
Viterbi, IDR, 1544
Viterbi, IDR, 1544
Viterbi, IDR, 2048
Viterbi, IDR, 2048
Viterbi, IDR, 6312 & 8448
Viterbi, IDR, 6312 & 8448
Viterbi and R-S, IDR, 1544
Viterbi and R-S, IDR, 1544
Viterbi and R-S, IDR, 2048
Viterbi and R-S, IDR, 2048
Viterbi and R-S, IDR, 6312 &
8448
Viterbi and R-S, IDR, 6312 &
8448
Trellis and R-S, IDR
Viterbi, IBS
Viterbi, IBS
Viterbi and R-S, IBS
Viterbi and R-S, IBS
Trellis and R-S, IBS
Viterbi and R-S, IBS
Viterbi and R-S, IBS
Viterbi and R-S
Viterbi and R-S
Viterbi and R-S
Trellis and R-S
3-7
Revision 4
MN/SLM7650.IOM
Min DR (kbps) Max DR
(Mbps)
9.60 8.448
12.30 8.448
14.35 8.448
64.00 8.448
80.00 8.448
256.00 8.448
256.00 8.448
1544.00 1.544
1544.00 1.544
2048.00 2.048
2048.00 2.048
6312.00 8.448
6312.00 8.448
1544.00 1.544
1544.00 1.544
2048.00 2.048
2048.00 2.048
6312.00 8.448
6312.00 8.448
1544.00 8.448
64.00 8.448
64.00 8.448
64.00 8.333
64.00 8.448
64.00 1.536
64.00 8.448
64.00 8.448
64.00 4.589
64.00 8.448
64.00 8.448
64.00 1.536
