SLM-7650 Satellite Modem
Remote Control Specifications
Solomon Response:
Encoder
Enable
Status:
Response:
Transmit Command:
BPSK Data Response:
Ordering
Status:
Response:
Carrier Only Command:
Mode Response:
Status:
Response:
TX 8PSK Command:
IESS-310 Response:
Operation
Status:
Response:
Modulator Command:
Encoder Response:
Type
Status:
Response:
Modulator Command:
Reed- Response:
Solomon
Codeword Status:
Response:
Bulk Command:
Configur- Response:
ation
Status:
Response:
>add/RSEN_xxx'cr'
RF_OFF'cr''lf']
<add/RSEN_'cr'
>add/RSEN_xxx'cr''lf']
<add/TDA_xxx'cr'
>add/TDA_xxx'cr''lf']
<add/TDA_'cr'
>add/TDA_xxx'cr''lf']
<add/COM_xxxxxx'cr'
>add/COM_xxxxxx'cr''lf']
<add/COM_'cr'
>add/COM_xxxxxx'cr''lf']
<add/T310_xxx'cr'
>add/T310_xxx'cr''lf']
<add/T310_'cr'
>add/T310_xxx'cr''lf']
<add/MET_xxx'cr'
>add/MET_xxx'cr''lf']
<add/MET_'cr'
>add/MET_xxx'cr''lf']
<add/MRSC_nnn_kkk_i'cr'
>add/MRSC_nnn_kkk_i'cr''lf']
<add/MRSC_'cr'
>add/MRSC_nnn_kkk_i'cr''lf']
<add/BMC_p1,p2, . . . pn'cr'
>add/BMC_p1,p2, . . . pn'cr''lf']
<add/BMC_'cr'
>add/BMC_p1,p2, . . .pn'cr''lf']
Parameter 1:
Parameter 2:
Parameter 3:
Parameter 4:
Parameter 5:
Parameter 6:
Parameter 7:
Parameter 8:
Parameter 9:
Where: xxx = NRM (STANDARD) or INV (NON-
STANDARD).
Where: xxxxxx = OFF (NORMAL-MODULATED), DUAL
(DUAL-CW), OFFSET (OFFSET-CW), CENTER (CENTER-
CW).
Where: xxx = ON or OFF.
Where xxx = VIT (Viterbi) or TUR (Turbo).
Where nnn_kkk_i = 225_205_8, 225_205_4, 219_201_8,
219_201_4, 194_178_4, or 126_112_4.
Note: This command is valid only in modem type "CUSTOM"
when overhead type is "NONE" or "ASYNC". Status is
available at all times.
This command causes the modulator to be programmed
with supplied parameters. All parameters are separated by a
',' (comma) except for the last parameter which has the
standard command termination character ('cr'). Parameters
that do not need to be changed can be nulled (no data
between comma's).
Modulator RF output (ref. "RF_" command).
P1 = n, where 'n' is '0' to indicate off or '1' to indicate on..
Modulator output power level (ref. "MOP_" command).
P2 = snn.n, transmitter output power level in dBm.
Modulator IF frequency (ref. "MF_" command).
P3 = nnn.nnnnnn, IF frequency in MHz.
Modulator Rate Variable Assign & Selection (ref. "MR_")
P4 = nnnn_mmmm.mmm, code rate/data rate in Kbps.
Reed Solomon Encoder Enable (ref. "RSEN_"
command).
P5 = n, where 'n' is '0' to indicate off or '1' to indicate on.
Interface transmit overhead type (ref. "ITOT_"
command).
P6 = n, where 'n' is '0' (NONE), '1' (IDR), or '2' (IBS), '3' (DI),
'4' (ASYNC), '5' (IBS309), '6' (VSAT-IBS).
Modulator type (ref. "MT_" command).
P7 = n, where 'n' is '0' or '1'(0=EFD,1=INTL)
Scrambler enable (ref. "SE_" command).
P8 = n, where 'n' is '0' to indicate off or '1' to indicate on.
Differential encoder enable (ref. "DENC_" command).
P9 = n, where 'n' is '0' to indicate off or '1' to indicate on.
A–6
Revision 4
MN/SLM7650.IOM
