Comtech EF Data SLM-7650 Installation And Operation Manual page 163

SLM-7650 Satellite Modem
Remote Control Specifications
System Reset Command:
Response:
A.12 Automatic Uplink Power Control (AUPC)
AUPC Local Command:
Enable Response:
Status:
Response:
AUPC Nominal Command:
Power Level Response:
Status:
Response:
AUPC Command:
Maximum Response:
Power Limit
Status:
Response:
AUPC Command:
Minimum Response:
Power Limit
Status:
Response:
AUPC Eb/N0 Command:
Target Set Response:
Point
Status:
Response:
AUPC Command:
Maximum Response:
Tracking Rate
Status:
Response:
AUPC Local Command:
Carrier Loss Response:
Action
Status:
Response:
AUPC Remote Command:
Carrier Loss Response:
Action
Status:
Response:
<add/SYSR!_xxxx'cr'
>add/SYSR!_xxxx'cr''lf'
<add/LPC_xxx'cr'
>add/LPC_xxx'cr''lf']
<add/LPC_'cr'
>add/LPC_xxx'cr''lf']
<add/NOMP_snn.n'cr'
>add/NOMP_snn.n'cr''lf']
<add/NOMP_'cr'
>add/NOMP_snn.n'cr''lf']
<add/MAXP_snn.n'cr'
>add/MAXP_snn.n'cr''lf']
<add/MAXP_'cr'
>add/MAXP_snn.n'cr''lf']
<add/MINP_snn.n'cr'
>add/MINP_snn.n'cr''lf']
<add/MINP_'cr'
>add/MINP_snn.n'cr''lf']
<add/ENSP_nn.n'cr'
>add/ENSP_nn.n'cr''lf']
<add/ENSP_'cr'
>add/ENSP_nn.n'cr''lf']
<add/MAXT_n.n'cr'
>add/MAXT_n.n'cr''lf']
<add/MAXT_'cr'
>add/MAXT_n.n'cr''lf']
<add/LCL_xxxx'cr'
>add/LCL_xxxx'cr''lf']
<add/LCL_'cr'
>add/LCL_xxxx'cr''lf']
<add/RCL_xxxx'cr'
>add/RCL_xxxx'cr''lf']
<add/RCL_'cr'
>add/RCL_xxxx'cr''lf']
Where: xxxx = HARD or SOFT
Note: HARD reset initializes and reprograms all modules to
system default configuration values while SOFT reset
initializes and reprograms all modules to currently
programmed configuration values
Where: xxx = ON or OFF.
Notes:
1. When programmed ON, the MOP (Modulator Output Power)
command is not allowed, only MOP status is allowed.
2. ASYNC Overhead only.
Where: snn.n = -30.0 to +5.0, in 0.1 steps (nominal range in dBm).
Notes:
1. ASYNC Overhead only.
Where: snn.n = -30.0 to +5.0, in 0.1 steps (nominal range in dBm).
Notes:
1. ASYNC Overhead only.
Where: snn.n = -30.0 to +5.0, in 0.1 steps (nominal range in dBm).
Notes:
1. ASYNC Overhead only.
Where: nn.n = 3.2 to 16.0, in 0.1 increments (Eb/N0 in dB).
Note: ASYNC Overhead only.
Where: n.n = 0.5 to 6.0, in 0.5 increments (max tracking rate in
dBm/minute).
Note: ASYNC Overhead only.
Where: xxxx = HOLD, NOM, or MAX (power level setting when local
carrier loss).
Note: ASYNC Overhead only.
Where: xxxx = HOLD, NOM, or MAX (power level setting when remote
carrier loss).
Note: ASYNC Overhead only.
A–21
Revision 4
MN/SLM7650.IOM
