SLM-7650 Satellite Modem
Remote Control Specifications
A.18 Bulk Status
Bulk Command:
Consol. Response:
Analog
Status
Where 'pn' is the last parameter returned.
Parameter
Number
1
2
3
4
5
6
7
Note: Parameters 2 through 7 are dependent on carrier acquisition, if the decoder is not locked empty data blocks are returned (,,,,,).
Bulk Command
Consol. :
Status Response:
<add/BCAS_'cr'
>add/BCAS_p1,p2,p3, . . . pn'cr''lf']
Parameter Name
(Command Reference)
Receive Signal Level
(ref. 'RSL_' command).
Raw BER
(ref. 'RBER_' command).
Corrected BER
(ref. 'CBER_' command).
Interface Read Error Status
(ref. 'IRES_' command).
EB/N0
(ref. 'EBN0_' command).
Buffer Fill Status
(ref. 'IBFS_' command).
Frame BER Status
(ref. 'FBER_' command).
<add/BCS_'cr'
>add/BCS_p1,p2,p3, . . . pn'cr''lf']
This command is similar to the 'BCS_' command, but returns
modem analog parameters. Additional status of new options
and features will always be appended to the end.
Description
p1 = xsnn.n, receive signal level in dBm.
p2 = xm.mE-ee.
p3 = xm.mE-ee.
p4 = tttt_xm.mE-ee.
p5 = xnn.n, EB/N0 in dB.
p6 = nn%, buffer fill status.
p7 = xm.mE-ee.
This command causes bulk modem status to be returned. To
reduce the length of the response, message parameter data
are returned without identifiers. However, parameter
identification can be determined by order of return. Each
status parameter is terminated with a ',' (comma) except for
the last parameter which has the standard message
termination sequence ('cr''lf']). Most of the data returned is
formatted the same way as the single command status
request (refer to the appropriate portions of this document in
preceding sections). Additional configuration status of new
options and features will always be appended to the end.
