SLM-7650 Satellite Modem
Remote Control Specifications
A.10 Interface Configuration Commands
Interface Command:
Transmit Response:
Overhead
Type
Status:
Response:
Interface Command:
Receive Response:
Overhead
Type Status:
Response:
Transmit Command:
Clock Response:
Status:
Response:
SCT PLL Command:
Reference Response:
Status:
Response:
External Command:
Clock- Response:
Reference
Frequency Status:
Response:
Transmit Command:
Clock Phase Response:
Status:
Response:
Buffer Clock Command:
Response:
Status:
Response:
Receive Clock Command:
Phase Response:
Status:
Response:
Baseband Command:
Loopback Response:
Status:
Response:
<add/ITOT_xxxxx'cr'
>add/ITOT_xxxxx'cr'
RF_OFF 'cr''lf']
<add/ITOT_'cr'
>add/ITOT_xxxxx'cr''lf']
<add/IROT_xxxxx'cr'
>add/IROT_xxxxx'cr''lf']
<add/IROT_'cr'
>add/IROT_xxxxx'cr''lf']
<add/TC_xxxx'cr'
>add/TC_xxxx'cr''lf']
<add/TC_'cr'
>add/TC_xxxx'cr''lf']
<add/MSPR_xxx'cr'
>add/MSPR_xxx'cr''lf']
<add/MSPR_'cr'
>add/MSPR_xxx'cr''lf']
<add/ERF_nnnnn.n'cr'
>add/ERF_nnnnn.n'cr''lf']
<add/ERF_'cr'
>add/ERF_nnnnn.n'cr''lf']
<add/TCP_xxx'cr'
>add/TCP_xxx'cr''lf']
<add/TCP_'cr'
>add/TCP_xxx'cr''lf']
<add/BC_xxx'cr'
>add/BC_xxx'cr''lf']
<add/BC_'cr'
>add/BC_xxx'cr''lf']
<add/RCP_xxx'cr'
>add/RCP_xxx'cr''lf']
<add/RCP_'cr'
>add/RCP_xxx'cr''lf']
<add/BBL_xxx'cr'
>add/BBL_xxx'cr''lf']
<add/BBL_'cr'
>add/BBL_xxx'cr''lf']
Where: xxxxx = NONE, IDR, IBS, DI, ASYNC, IBS-309, or
VSAT-IBS
Where: xxxxx = NONE, IDR, IBS, DI, ASYNC, IBS-309, or
VSAT-IBS
Where: xxxx = INT (internal SCT clock), EXT (external TX
terrestrial clock) or DATA (data clock sync).
Where: XXX = MR (modem reference), ERF (external clock,
"MC/EXC")
Default is MR.
When transmit clock source is selected as "DATA" the ST
Reference Clock Source defaults to "DATA" no matter
what MSPR_ parameter is selected. See TC_ command.
Where: nnnnn.n = 9.6 to 20000.0 (external clock frequency
in kHz).
*Note: Specifies the frequency of External Master Clock
input.
Where: xxx = NRM (normal clock phasing) or INV (inverted
clock phasing).
Where: xxx = INT (internal clock), EXT (external TX
terrestrial clock), SAT (receive satellite clock), REF (external
clock-reference frequency), or INS (insert clock).
Where: xxx = NRM (normal clock phasing) or INV (inverted
clock phasing).
Where: xxx = ON or OFF.
