SLM-7650 Satellite Modem
Remote Control Specifications
Interface
Command:
Receive
Response:
Side Stored
Faults
Common
Command:
Equipment
Response:
Stored
Faults
Interface
Command:
Backward
Response:
Alarms
Stored
Faults
<add/IRSF_#'cr'
>add/IRSF_# hh:mm:ss MM/DD/YYYY'cr'
MOD_xxx'cr'
PLL_xxx'cr'
CLK_xxx'cr'
RXD_xxx'cr'
DMUX_xxx'cr'
2047_xxx'cr'
OVFL_xxx'cr'
UNFL_xxx'cr'
BUFF_xxx'cr'
INS_xxx'cr'
BWA_xxx'cr'
FBER_xxx'cr''lf']
<add/CSF_#'cr'
>add/CSF_# hh:mm:ss MM/DD/YYYY'cr'
M&C_xxx'cr'
BAT_xxx'cr'
–12V_xxx'cr'
+12V_xxx'cr'
+5V_xxx'cr'
+3.3V_xxx'cr'
+2.5V_xxx'cr'
+1.8V_xxx'cr'
TEMP_xxx'cr'
PLL_xxx'cr'
ACT_xxx'cr''lf']
<add/IASF_#'cr'
>add/IASF_# hh:mm:ss MM/DD/YYYY'cr'
TXBWA1_xxx'cr'
TXBWA2_xxx'cr'
TXBWA3_xxx'cr'
TXBWA4_xxx'cr'
RXBWA1_xxx'cr'
RXBWA2_xxx'cr'
RXBWA3_xxx'cr'
RXBWA4_xxx'cr''lf']
Module (OK/FLT)
Buffer Clock PLL Lock (OK/FLT)
Selected Buffer Clock Activity (OK/FLT)
Receive Data Loss/AIS (OK/FLT)
Demux/Reed-Solomon Lock (OK/FLT)
2047 Pattern Lock Detect (OK/FLT)
Buffer Overflow (OK/FLT)
Buffer Underflow (OK/FLT)
Buffer Full (OK/FLT)
D&I Insert (OK/FLT)
Receive Backward Alarm (OK/FLT)
Frame BER (OK/FLT)
M&C (OK/FLT)
Battery/Clock (OK/FLT)
-12 Volt Level (OK/FLT)
+12 Volt Level (OK/FLT)
+5 Volt Level (OK/FLT)
+3.3 Volt Level (OK/FLT)
+2.5 Volt Level (OK/FLT)
+1.8 Volt Level (OK/FLT)
Temperature (OK/FLT)
Modem Reference PLL (OK/FLT)
Modem Reference Activity (OK/FLT)
TX Backward Alarm 1 (OK/FLT)
TX Backward Alarm 2 (OK/FLT)
TX Backward Alarm 3 (OK/FLT)
TX Backward Alarm 4 (OK/FLT)
RX Backward Alarm 1 (OK/FLT)
RX Backward Alarm 2 (OK/FLT)
RX Backward Alarm 3 (OK/FLT)
RX Backward Alarm 4 (OK/FLT)
A–50
Revision 4
MN/SLM7650.IOM
