SLM-7650 Satellite Modem
Remote Control Specifications
MAXT_n.n'cr' (Note 2)
RTSM_xxx'cr'
TAS_xx'cr' (Note 9)
DIL_xxx'cr''lf'] (Note 10)
AUPC Max. Tracking Rate
RTS TX-IF Control Mode
Terrestrial ASYNC Source
DDO/IDI Loopback
The Interface configuration status command causes a
block of data to be returned by the addressed MODEM.
The block reflects the current configuration of the
interface. Additional configuration status of new options
and features will always be appended to the end.
Notes:
1. Data is only returned for TX ASYNC Overhead.
2. Data is only returned for RX ASYNC Overhead.
3. Data is only returned for TX or RX ASYNC
Overhead.
4. Data is only returned when the option card is
installed and RX overhead is IDR.
5. Data is only returned when the option card is
installed and TX overhead is IDR.
6. Data is only returned when the option card is
installed and RX overhead is DI.
7. Data is only returned when the option card is
installed and TX overhead is DI.
8. Data is only returned when the option card is
installed.
9. Data is only returned when the option card is
installed and TX or RX Overhead is ASYNC.
10. Data is only returned when the option card is
installed and TX or RX Overhead is DI.
