SLM-7650 Satellite Modem
Remote Control Specifications
Status
(continued)
Parameter
Number
53
54
(Note 5)
55
(Note 5)
56
(Note 6)
57
(Note 6)
58
59
60
61
62
63
64
(Note 3)
65
(Note 4)
66
(Note 3)
67
(Note 4)
68
69
70
Parameter Name
(Command Reference)
Transmit data fault
(ref. 'TDF_' command).
Receive data fault
(ref. 'RDF_' command).
Interface Service Channel TX1
(ref. 'ISCL_' command).
Interface Service Channel TX2
(ref. 'ISCL_' command).
Interface Service Channel RX1
(ref. 'ISCL_' command).
Interface Service Channel RX2
(ref. 'ISCL_' command).
System modem type
(ref. 'SMT_' command).
Modem operation mode
(ref. 'MOM_' command).
MODEM REMOTE/LOCAL mode.
Transmit data phase
(ref. 'TDP_' command).
Receive data phase
(ref. 'RDP_' command).
Drop Data Format
(ref. 'DDF_' command).
Insert Data Format
(ref. 'IDF_' command).
Bulk Drop Channels Assignment
(ref. 'BDCA_' command).
Bulk Insert Channels Assignment
(ref. 'BICA_' command).
reserved null field.
Modem Reference Clock
(ref. 'MRC_' command).
Modulator Spectrum Rotation
(ref. 'MSR_' command).
Description
p53 = n, where 'n' is '0' (NONE), '1' (DATA), or '2' (AIS).
p54 = n, where 'n' is '0' (NONE), '1' (DATA), or '2' (AIS).
p55 = nnn, service channel level in dB.
p56 = nnn, service channel level in dB.
p57 = nnn, service channel level in dB.
p58 = nnn, service channel level in dB.
p59 = n, where 'n' is '0' (IDR), '1' (IBS), '2' (EFD), '3'
(CUSTOM), '4' (DI), '7' (ASYNC), '8' (7650-00), '9'
(7650-02), '10' (IBS-309), or '11' (VSAT-IBS).
p60 = n, where 'n' is '1' (TX_ONLY), '2' (RX_ONLY), '3'
(DUPLEX).
p61 = n, where 'n' is '0' (LOCAL), '1' (REMOTE).
p62 = n, where 'n' is '0' (NRM), '1' (INV).
p63 = n, where 'n' is '0' (NRM), '1' (INV).
p64 = n, where 'n' is '0' (T1), '1' (T1ESF), '2' (E1CCS), or '3'
(E1CAS).
p65 = n, where 'n' is '0' (T1), '1' (T1ESF), '2' (E1CCS), or '3'
(E1CAS).
p66 = dd;cc_dd;cc_dd;cc_dd;cc..., as defined by the
'BDCA_' command.
p67 = dd;cc_dd;cc_dd;cc_dd;cc..., as defined by the 'BICA_'
command.
p69 = n, where 'n' is '0' (INT), '4' (EXT1), '1' (EXT5), '2'
(EXT10), or '3' (EXT20) respectively.
p70 = n, where 'n' is '0' (NRM), '1' (INV).
