SLM-7650 Satellite Modem
Remote Control Specifications
A.13 Status Commands/Responses
A.13.1 Modulator Configuration Status
Modulator Command:
Config. Response:
Status
<add/MCS_'cr'
>add/MCS_'cr'
RF_xxx'cr'
MF_nn.nnnnnnn'cr'
MR_nnnn_mmmmm.mmm'cr'
AMRA_nnnn_mmmmm.mmm'cr'
AMRB_nnnn_mmmmm.mmm'cr'
AMRC_nnnn_mmmmm.mmm'cr'
AMRD_nnnn_mmmmm.mmm'cr'
AMRV_nnnn_mmmmm.mmm'cr'
MPO_snn.n'cr'
MOP_snn.n'cr'
SE_xxx'cr'
DENC_xxx'cr'
MT_xxxxx'cr'
MET_xxx'cr'
COM_xxxxxx'cr'
MRC_xxx'cr'
MSR_xxx'cr'
RSEN_xxx'cr'
MSPR_xxx'cr'
TDA_xxx'cr'
SCRT_xxxx'cr'
T310_xxx'cr'
MRSC_nnn_kkk_i'cr''lf'] (Note 1)
RF Output
Modulator Frequency
Modulator Rate
Preset 'A' Assignment
Preset 'B' Assignment
Preset 'C' Assignment
Preset 'D' Assignment
Preset 'V' Assignment
Modulator Power Offset
Modulator Output Power
Scrambler Enable
Differential Encoder
Modulator Type
Modulator Encoder Type
Carrier Only Mode
Modem Reference Clock
Modulator Spectrum Rotation
Reed-Solomon Encoder
SCT PLL Reference
Transmit BPSK Data Ordering
Scrambler Type
TX 8PSK IESS-310 Operation
Reed-Solomon Codeword
The modulator configuration status command causes a
block of data to be returned by the addressed modem. The
block of data reflects the current configuration status of the
modulator module. Additional configuration status of new
options and features will always be appended to the end.
Notes:
1. Data is only returned when the modem type is set to
CUSTOM and TX Overhead is either NONE or ASYNC.
