SLM-7650 Satellite Modem
Remote Control Specifications
Parameter 13:
Parameter 14:
Parameter 15:
Parameter 16:
Parameter 17:
Parameter 18:
Parameter 19:
Parameter 20:
Parameter 21:
Parameter 22:
Parameter 23:
Parameter 24:
Parameter 25:
Parameter 26:
Parameter 27:
Parameter 28:
Parameter 29:
Parameter 30:
Parameter 31:
Parameter 32:
Receive clock phase (ref. "RCP_" command).
P13 = n, where 'n' is '0' or '1' (0 = NRM or 1 = INV).
Receive data phase (ref. "RDP_" command).
P14 = n, where 'n' is '0', '1' (0 = NRM, 1 = INV).
Receive BPSK Data Ordering (ref. "RDA_" command).
P15 = n, where 'n' is '0', '1' (0 = NRM, 1 = INV).
Buffer Programming Mode
P16 = n, where 'n' is '0', '1' ( 0 = BITS, 1 = MILLISECONDS)
Buffer Size (ref. "IBS_" command).
P17 = nnnnnn, where 'nnnnnn' = 32 to 1048576 bits (p16=0)
Sweep Reacquisition (ref. "SR_" command).
P18 = nnn, where: 'nnn' = 0 to 999 seconds.
Interface Read Error Select (ref. "IRE_" command).
P19 = n, where 'n' is '0' to '2'
(0=OFF,1=2047/ON,2=MIL188).
Receive data fault (ref. "RDF_" command).
P20 = n, where 'n' is '0', '1' to '2' (0=NONE,1=DATA,2=AIS).
Descrambler Type (ref. "DCRT_" command).
P21 = n where n = '0' (IESS), '1' (OM73), or '2' (TURBO).
Sweep Center Frequency (ref. "SCF_" command).
P22 = snnnnn, where: snnnnn is the sweep center frequency
in Hz.
IF Loopback (ref. "IFL_" command).
P23 = n, where: 'n' is '0' to indicate off or '1' to indicate on.
ASYNC RX Baud Rate (ref. "ROBR_" command).
P24 = n, where: 'n' is '0' = 110 baud,
ASYNC RX Character Length (ref. "RCCL_" command).
P25 = n, where: 'n' is '7' or '8' bits.
ASYNC RX Stop Bits (ref. "RCSB_" command).
P26 = n, where: 'n' is '1' or '2' bits.
ASYNC RX Parity (ref. "ROCP_" command).
P27 = n, where: 'n' is '0' = NONE,
Reserved.
T1 Frame Structure (ref. "IRFS_" command).
P29 = n, where: 'n' is '0' = NONE or '1' = G.704
E1 Frame Structure (ref. "IRFS_" command).
P30 = n, where: 'n' is '0' = NONE or '1' = G.704
T2 Frame Structure (ref. "IRFS_" command).
P31 = n, where: 'n' is '0' = NONE,
E2 Frame Structure (ref. "IRFS_" command).
P32 = n, where: 'n' is '0' = NONE,
A–12
Revision 4
MN/SLM7650.IOM
= 1 to 48 ms
'1' = 150 baud,
'2' = 300 baud,
'3' = 600 baud,
'4' = 1200 baud,
'5' = 2400 baud,
'6' = 4800 baud,
'7' = 9600 baud,
'8' = 19200 baud,
'9' = 38400 baud
'1' = EVEN,
'2' = ODD
'1' = G.704,
'3' = G.743,
'5' = G.747
'1' = G.704,
'2' = G.742,
'4' = G.745
(p16=1)
