Which Trend Graph Do You See? (continued from page
before)
(Scroll down from the 6-hour graph to reach the 12-hour graph)
(Scroll down from the 12-hour graph to reach the 24-hour graph)
The receiver displays "LOW" when the most recent sensor glucose
reading is less than 40 mg/dL and "HIGH" when the most recent sensor
glucose reading is greater than 400 mg/dL.
8.2 RATE OF CHANGE ARROWS IN REAL-TIME
MODE
The rate of change arrows add detail about the direction and speed of
glucose change over the last 15-20 minutes.
12-Hour Trend Graph: The 12-hour trend graph
shows the current sensor glucose reading and the
last 12 hours of sensor glucose readings.
24-Hour Trend Graph: The 24-hour trend graph
shows the current sensor glucose reading and the
last 24 hours of sensor glucose readings.
Trend graph
reading LOW
Dexcom G4 PLATINUM Professional System User's Guide
Trend graph
reading HIGH
| 97
