1
Display screen
Receiver buttons:
• Press the UP and
highlight menu items, or set values.
• Press the SELECT
highlighted option.
• Press the LEFT
• Press the RIGHT

1.6 RECEIVER SHIELD OVERVIEW

The Dexcom G4 PLATINUM Professional System requires the use of
the receiver shield and its components to help protect the receiver from
contamination. The receiver shield pack includes the receiver shield, 3
square seals, 1 triangle seal and 1 acoustic spacer.
20 | Dexcom G4 PLATINUM Professional Continuous Glucose Monitoring System
UP button
LEFT DOWN
button button
DOWN buttons to scroll through trend screens,
button to turn the receiver on or select the
button to go back to the last item or screen.
button to highlight the next item.
Speaker USB port cover
RIGHT
button
SELECT
button
USB port
