Dexcom G4 Professional User Manual page 151

12
4. Remove and discard the triangle seal
that is over the t-shaped slot in the back
of the receiver.
5. Hold one corner of the shield near the
top of the t-shaped slot. Stretch that
corner of the shield off the receiver.
6. Hold the other corner of the shield near the top of the t-shaped slot.
Stretch that corner of the shield off the receiver.
7. Peel back the shield, being careful
not to touch the outside of the shield
or gloved hands to the surface of the
receiver.
8. Hold the edge of the shield that is still on the receiver, just above a
clean surface.
150 | Dexcom G4 PLATINUM Professional Continuous Glucose Monitoring System
Step 4. Remove triangle seal
Step 5. Stretch corner of
shield off the receiver
Step 7. Peel back shield
