Chrysler PT Cruiser Service & Repair Manual page 946

8W - 80 - 82 8W-80 CONNECTOR PIN-OUTS
RIGHT CITY LAMP (EXPORT) - GRAY 2 WAY
CAV CIRCUIT
1 Z1 18BR
2 L7 18BK
RIGHT CYLINDER LOCK SWITCH (EXPORT) - BLACK 2 WAY
CAV CIRCUIT
1 P96 20LG
2 Z1 20BK
RIGHT DOOR LOCK SWITCH - BLACK 3 WAY
CAV CIRCUIT
1 L7 18BK/YL
2 P96 18LG
2 P96 20WT/DG
3 Z1 18BK
CAV CIRCUIT
A L39 18LB
B Z1 18BK
GROUND
HEADLAMP SWITCH OUTPUT
RIGHT DOOR SWITCH MUX
GROUND
HEADLAMP SWITCH OUTPUT
RIGHT DOOR SWITCH MUX
RIGHT DOOR SWITCH MUX
GROUND
RIGHT FOG LAMP - GRAY 2 WAY
FOG LAMP SWITCH OUTPUT
GROUND
PT
FUNCTION
FUNCTION
FUNCTION
FUNCTION
