Figure 59. SAN Volume Controller 2145-8G4 support rails installation kit
1
Rear of rail
2
Rack mounting rails
3
M6 screws
4
Latches
5
Front of rail
Note: You might find it helpful, with some types of racks, to remove the rack doors and side panels
to provide easier access during installation.
2. Check the labels on the support rails. Each rail has a label that indicates which is the front end of the
rail and whether the rail is for the left or right side of the rack. Perform this procedure for both rails.
3. Insert the right slide rail
1
pins protruding through the flange.
2
Figure 60. Inserting the right slide rail into the rear rack mounting flange
4. Extend the right slide rail
on page 65, with the rail pins
way.
64
IBM SAN Volume Controller Hardware Maintenance Guide
2
into the rear rack mounting flange, as shown in Figure 60, with the rail
2
and insert it into the front rack mounting flange, as shown in Figure 61
1
protruding through the flange. Insert the left slide rail in the same
