Table 3. FRUs in the SAN Volume Controller 2145-CF8 parts assembly
Assembly
index Part number
-1 44T1493
-2 31P1340
-3 33F8354
-4 31P1337
e
e
e
e
e
e
e
e
e
-5 39Y7201
-6 44E4372
-7 42D0673
-8 44T2248
-9 31P1339
-10 43V7071
-11 43V6929
-12 43V7072
Units Description
6 Memory module
4 GB memory module, DDR3-1333 2RX4 LP RDIMM
1 Optional: High speed SAS adapter
An assembly that includes a high speed SAS adapter card that
provides connectivity for up to four solid-state drives (SSDs), a
riser card, a blanking plate, and screws.
1 CMOS battery
3.0 volt battery on the system board that maintains power to back
up system BIOS settings.
1 4-port fibre-channel adapter
A fibre-channel host bus adapter (HBA) assembly that connects
the SVC CF8 to the fibre-channel fabric. It is located in PCI slot 1.
The adapter assembly includes the fibre-channel PCI Express
adapter, four short-wave small form-factor pluggable (SFP)
transceivers, the riser card, and the bracket.
Note: If the system is using alternative fibre-channel SFP
transceivers, replace the SFP transceivers on the FRU part with
the SFP transceivers from the fibre-channel adapter that is being
replaced.
2 Power supply unit
Ac power supply, 675 Watt
1 Operator-information panel
This assembly includes the information panel that contains the
power-control button and diagnostics LEDs.
1 Disk drive
The serial-attached SCSI (SAS) 2.5 inch disk drive, which, when
ordered as a replacement, might be a supported compatible drive
of at least the same capacity as the one being replaced.
4 Drive bay blank EMC filler assembly
1 Service controller
The service controller includes the front-panel display, buttons,
and associated electronics.
1 Disk backplane
Hot-swap SAS 2.5" disk-drive backplane
6 Fan assembly
The fan assembly is used in each of the six fan positions.
1 System board
The system board is also called the planar.
Note: This part is the system board only. When replaced, you
must also have alcohol wipes and thermal grease.
3
Chapter 1. Parts listing
