board.
Figure 119. SAN Volume Controller 2145-8A4 SATA cable connectors
9. Rotate (lift) the air deflector
Figure 120. Air deflector for the SAN Volume Controller 2145-8A4 power supply
10. Slightly lift the back plate out of the node. Disconnect power cable connectors P2
shown in Figure 121 on page 119, and remove the back plate.
118
IBM SAN Volume Controller Hardware Maintenance Guide
1
out of the way, as shown in Figure 120.
1
1
2
and P3
,
